• Optoelectronic Technology
  • Vol. 44, Issue 1, 6 (2024)
Wenzhu WU, Zengzhou YANG, Zugang LIU, Jiawei JING..., Ranran HAN, Jinchen HAN, Zhijie XIA, Hong ZHAO and Xin YAO|Show fewer author(s)
Author Affiliations
  • College of Optical and Electronic Technology,China Jiliang University, Hangzhou 310018, CHN
  • show less
    DOI: 10.12450/j.gdzjs.202401002 Cite this Article
    Wenzhu WU, Zengzhou YANG, Zugang LIU, Jiawei JING, Ranran HAN, Jinchen HAN, Zhijie XIA, Hong ZHAO, Xin YAO. Method Synthesis of CuIn0.7Ga0.3S2 Nanoparticles by Injection Method and Application in CIGSSe Solar Cells[J]. Optoelectronic Technology, 2024, 44(1): 6 Copy Citation Text show less

    Abstract

    Copper indium gallium selenide (CIGS) solar cells have been extensively researched for their outstanding performance. Solution-based preparation techniques offer significant potential for large-scale industrialization. CuIn0.7Ga0.3S2 nanoparticles were synthesized at 200 ℃ via a hot injection method. The method maintained the quantity of Cu, In, and Ga of raw materials while precisely controlling the composition of Cu, In, Ga, and S elements by adjusting the volumes of surfactant oleylamine, solvent dibenzyl ether, and coordinating agent 1-octadecanethiol to 80 ml, 4 ml, and 15 ml, respectively. The atomic ratio of the synthesized nanoparticles was 1∶0.688∶0.299∶2.03, corresponding to CuIn0.688Ga0.299S2.03, with the nanoparticles' size ranging from 5 to 20 nm. The nanoparticles were purified and cleaned using organic solvents with different polarity, resulting in stable dispersion of the nanoparticles in toluene, as well as other more environmentally friendly solvents, such as o-xylene and cyclohexane. With these nanoparticle-based inks with different solvents, the copper indium gallium selenide sulfide (CIGSSe) absorber layers and their thin film solar cells were prepared.
    Wenzhu WU, Zengzhou YANG, Zugang LIU, Jiawei JING, Ranran HAN, Jinchen HAN, Zhijie XIA, Hong ZHAO, Xin YAO. Method Synthesis of CuIn0.7Ga0.3S2 Nanoparticles by Injection Method and Application in CIGSSe Solar Cells[J]. Optoelectronic Technology, 2024, 44(1): 6
