In the past two decades, exceptional point (EP) has had a far-reaching impact in various research fields ranging from quantum mechanics and acoustics to photonics. EP corresponds to a spectral singularity in the parameter space of a non-Hermitian system where at least two eigenvalues and their associated eigenfunctions simultaneously coalesce.1^–3 Such peculiar degeneracies give rise to a wealth of novel effects, such as parity-time phase transition, topological phase transition,4^,5 and self-intersecting Riemann surface.6 These exotic phenomena not only enrich non-Hermitian physics but also lead to many practical applications including coherent-perfect absorption,7^,8 EP sensing,9 nonreciprocal wave propagation,10^,11 reconfigurable topological lasers,12 and more.13^,14

For EP sensing applications, the whispering gallery mode (WGM) microtoroid has long been regarded as one of the most promising platforms.15^–20 In the presence of target particles, the induced perturbation leads to the splitting of resonant frequencies that are initially degenerated at the EP.21 As such, measuring the amount of frequency splitting enables us to acquire information about particle sizes. Remarkably, the WGM microtoroid operating at or close to EPs has been revealed to exhibit three-22 to seven-fold23 higher sensitivity as compared to that of conventional sensors, e.g., the WGM microtoroid operating near diabolic points (DPs) where only the system eigenvalues coalesce.

To widen the detectable range of particle dimensions, extending the working bandwidth of EP sensors is highly desirable. Nevertheless, EP sensors based on WGM microtoroid generally work at a particular order of WGM, i.e., a single frequency, due to the following two constraints.24 On the one hand, optical fields mainly concentrate inside the microtoroid, limiting the perturbation strength induced by external target particles. This limitation further hinders the above EP sensors in detecting subwavelength particles (with the minimum reported detectable size down to 0.258λ). In other words, such sensors must work at a sufficiently higher-order (or higher-frequency) mode to detect a particle in a given dimension. On the other hand, as the mode order (or frequency) further increases,25 the enhanced Q-factor dramatically lowers the excitation efficiency of WGM. In this case, the optical response of the sensor is too weak to detect the target particles. Thus, although a reconfigurable EP sensor (i.e., the one with tunable EPs) has long been sought after, its realization still confronts scientific challenges.

Spoof plasmonic resonators, e.g., spoof localized surface plasmon (LSP) resonators, emerge as an alternative platform for EP sensing.26^–31 A spoof LSP resonator refers to a periodically textured closed metallic structure that supports WGM-like modes (i.e., spoof LSPs) in multiple resonance frequencies.32^–38 Recently, an electrically controllable EP within a spoof LSP structure was first reported in the microwave domain, which is realized by perturbing plasmonic modes with an angled metal line and a varactor.38 Moreover, Zhang et al. proposed an EP sensor based on a chiral microwave spoof LSP resonator working at the fundamental dipole mode.39 Despite their similarity to WGMs in the spectrum, spoof LSPs are strongly localized at the surface or edge of resonators rather than within the bulk, which is a key merit that facilitates the realization of reconfigurable EP sensors.

First of all, the strong field confinement at the structural surface/edge largely enhances the perturbation strength from the surrounding target particles. The enhanced perturbation strength allows the detection of particles in the subwavelength scale (with the size down to 0.004λ39 and 0.012λ,40 as reported by recent experimental works). This also means that lower-order (i.e., lower-frequency) modes in the platform of spoof plasmonic resonators are now feasible to create EP,39 which is, however, unavailable in the platform of WGM resonators. Moreover, surface field enhancement also largely improves the excitation efficiency of multipolar modes, opening up an opportunity to form EP with high-order modes. Although recent advances38^–41 demonstrate the superior sensitivity of EP sensors constructed by spoof plasmonic resonators, the EP state is fixed and cannot be adjusted once the spoof plasmonic resonator is fabricated, indicating that the proposed schemes lack the degree of freedom to tune the EPs. In addition, the aforementioned scheme may fail to work at the EP state due to a tiny fabrication error. Therefore, although spoof plasmonic resonators offer a feasible solution to construct EP sensors, their realization of tunable and reconfigurable EP sensors remains unexplored.

To this end, we experimentally demonstrate reconfigurable and tunable EP sensors in the platform of spoof plasmonic resonators. The configuration consists of a spoof plasmonic resonator, a microstrip line, and two movable Rayleigh scatterers. Different from the conventional structural setup, the spoof plasmonic resonator is intentionally suspended above the microstrip line via an individual metal disk. We note that such a wise design has three main advantages. First, it leaves a sufficiently large space to tune the system to the EP state by adjusting the two Rayleigh scatterers. Second, it greatly improves the excitation efficiency of multipolar spoof LSPs. Third, it further enhances the perturbation strength of target particles. In addition, the mobility of Rayleigh scatterers offers a great degree of freedom to flexibly switch the EPs at distinct resonance mode in a broad range of frequencies. As we will show later, our experimental results successfully realize five consecutive EPs from sextupole, octupole, decapole, and dodecapole to 14-pole resonance modes. Owing to the extraordinarily strong perturbation strength, the proposed EP reconfigurable sensor exhibits superior sensitivity, with the minimum detectable dimension down to 0.001λ. Such a value is even a quarter magnitude of the recently reported result.39 Our work thus provides a novel paradigm for realizing flexible and highly sensitive particle detection from microwave to terahertz frequencies.

The schematic of the designed reconfigurable EP sensing system is shown in Fig. 1. The sensing system involves a single spoof plasmonic resonator suspended on the substrate and a microstrip line underneath. As the nature of spoof plasmonic structures, the resonator exhibits analogous characteristics to optical WGM cavities with multimode resonances, where each mode supports clockwise (CW) and counterclockwise (CCW) propagating waves with degenerate eigenfrequencies but orthogonal eigenvectors. In the absence of external perturbation, the proposed spoof plasmonic resonator operating at a DP supports equivalent magnitudes of CW and CCW propagating waves, thus spatially reflected as a standing-wave mode (see mode distribution in the bottom left of Fig. 1). When a single scatterer is placed close to the spoof plasmonic resonator, the scatterer will perturb the WGMs via the evanescent coupling. As a result, the coherent backscattering of counterpropagating waves will lift the spectral degeneracy with a doublet of standing-wave modes. Interestingly, when another scatterer with a proper size is introduced into this open system at a specific position, non-Hermitian degeneracy known as the second-order EP emerges, where eigenfrequencies and their corresponding eigenvectors coalesce simultaneously. Under this circumstance, the EP sensor displays fully asymmetric backscattering between the CW and CCW propagating waves, and only one of the traveling directions is dominant, as depicted in the bottom right of Fig. 1. Note that the above differences between spoof plasmonic resonators with and without EP apply to all the multipolar modes (see corresponding comparison of field distributions at the top of Fig. 1, and the phase distributions are illustrated in Sec. S1 in the Supplementary Material), further validating the implementation of reconfigurable EPs in five consecutive plasmonic resonance modes.

To demonstrate the advantage of the EP sensor, we theoretically compare its sensitivity with the DP sensor. In the DP sensor, the magnitude of frequency splitting is directly proportional to the perturbation strength, denoted as ε. However, for the resonator operating at second-order EPs, the splitting induced by the identical perturbation is proportional to ε1/2. Consequently, when encountering sufficiently small target particles, the EP sensor shows larger frequency splitting, which can be described as16^,22^,24ΔωEP=ΔωDP1+Aj(2)εei2mjα,(1)where ΔωDP=2·ε. mj denotes the mode number of plasmonic mode j and Aj(2) represents the unidirectional backscattering generated by second-order EPs. The perturbation strength of the target particle is ε=ε3 and the relative azimuthal angle is α=α3. In the case of |Aj(2)|≫|ε|, Eq. (1) can be simplified to ΔωEP=ΔωDPAj(2)εei2mjα=2Aj(2)εeimjα.(2)

Hence, the frequency splitting of EP sensors is proportional to ε1/2, indicating a reinforced capacity for detecting sufficiently small target particles. Thus, the spoof plasmonic sensor exhibits significantly enhanced sensitivity to external perturbations when operating at EPs. In addition, the sensitivity enhancement |ΔωEP/ΔωDP| is directly proportional to the square root of |Aj(2)| but inversely proportional to |ε| (see Sec. S2 in the Supplementary Material).

The proposed EP sensor is schematically illustrated in Figs. 2(a)–2(c), including the suspended spoof plasmonic resonator instead of the directly printed one.33^–39 Such a configuration leaves flexible space for EP state tuning, ensures effective excitation of multipolar modes, and enhances the perturbation strength of target particles (see Sec. S3 in the Supplementary Material for detailed explanations). The 2.82 mm-wide microstrip line overlaps with the resonator by dw=2mm along the y direction. The specific dimensions of the designed resonator are R=40mm (outer radius), r=20mm (inner radius), a=0.5d (periodicity), t=0.5mm (thickness), and N=60 (number of grooves). To facilitate the introduction of Rayleigh scattering particles and enhance the coupling between the resonator and the scatterers, a metal disk with a radius of Rd=r=20mm and a thickness of hd=2.5mm is fabricated, integrated with the resonator, and positioned between the spoof plasmonic resonator and the substrate. The radii of the scatterers are denoted by r1 and r2, respectively, and their relative azimuthal angle is α with the same thickness of 2 mm. In addition, the feeding line and the ground plane are both 35μm thick, while the F4B dielectric substrate has a thickness hs=0.93mm, relative permittivity εr=2.2, loss tangent tanδ=0.003, and side length ls=120mm.

For the simulations conducted using the commercial software CST Microwave Studio, we set the boundary conditions in the x, y, and z directions as open boundaries. In addition, we supplement these boundaries with a 30 mm-thick air layer in each direction, corresponding to one-quarter wavelength at the center frequency of the simulation bandwidth. Figure 2(d) shows the fabricated spoof plasmonic resonator and setup of the measurement. The transmission spectra of the DP sensor in the absence of external perturbation are shown in Fig. 2(e), which are captured through numerical simulations and measurements. Excellent agreements between the simulated and measured curves demonstrate that a series of plasmonic resonances are excited, which are denoted by nine dips from M1 to M9.

To experimentally demonstrate the tunability and reconfigurability of the EP spoof plasmonic sensor, we fabricated an aluminum-made resonator prototype and an F4B dielectric substrate using printed circuit board technologies, as shown in Fig. 2(d). The dimensions of the manufactured sensor are identical to those designed in Sec. 2.2. In the measurement, both ends of the microstrip line were connected with the Keysight N9927A vector network analyzer by SMA adaptors to measure the transmission and reflection spectra. To realize second-order EPs for each mode, we introduced a pair of deep-subwavelength Rayleigh scatterers into the evanescent-field regime of the spoof plasmonic resonator by carefully tailoring their radial positions and relative azimuthal angles. Compared with the DP, additional losses introduced by two scatterers not only broaden the linewidth of a specific resonance with enlarged frequency separation when working at the EP but also result in a reduction of the Q-factors of the system to a certain extent. To investigate the performance of this novel sensor, a copper particle was set as the target particle near the resonator and the relative azimuthal angle was set as α3=π with the same thickness as the scatterers mentioned earlier. In addition, these particles are fabricated from high-purity copper plates using precision laser cutting techniques.

In the proposed spoof plasmonic EP sensing system, we experimentally implement five distinct EPs at the sextu-, octu-, deca-, dodeca-, and fourteen-pole modes (from M3 to M7), respectively, with their resonance frequencies of 2.564, 2.765, 2.901, 3, and 3.11 GHz. To achieve EPs at each plasmonic mode, we set the first scatterer at an appropriate position (such as α1=0, below the right periphery of the resonator). Then, the second scatterer was deposited near the rim of the spoof plasmonic resonator. By adjusting the azimuthal position of the second scatterer carefully, the corresponding resonance modes degenerate in the transmission spectrum, demonstrating that the sensor is close to the EP state. However, the radial and azimuthal positions of both scatterers need to be slightly tuned until the reflection coefficients of different input ports reach the maximum deviation. One single broadened resonance dip and fully asymmetric reflection coefficients indicate the occurrence of EPs in the measurement, which correspond to non-Hermitian degeneracies of the resonance modes. Specifically, for five consecutive resonance modes (M3 to M7), the dimensions and positions of the corresponding pair of scatterers are listed in Table 1 and depicted in Figs. 3(a)–3(e). The details of particles, along with a comparison of S-parameters between the measured and simulated reconfigurable EPs, are discussed in Sec. S4 in the Supplementary Material.

As shown in Figs. 3(f)–3(j), the left panels show the resonance dip of the DP and EP sensors in the absence of the target particle. The introduction of two external scatterers leads to extra backscattering, resulting in a significant increase in the linewidth of the resonance dip. Meanwhile, the single target particle placed near the resonator (α3=π) lifts the degeneracy of corresponding eigenmodes, and the frequency splitting of EP sensors is noticeably greater than that of DP sensors. Furthermore, the sensitivity enhancements highlighted by black dashed lines are quite evident [see the right panels in Figs. 3(f)–3(j)]. As the essence of EPs, the scatterers utilized to establish EPs bring in extra losses, i.e., excess asymmetric backscattering between the counterpropagating waves. Therefore, when the signal is injected from one end of the microstrip line (such as port 1), the reflection spectrum exhibits a strong peak at the resonance frequency. On the contrary, the reflection almost disappears while injecting from the other port (such as port 2), as depicted in the insets of Figs. 3(f)–3(j). It is worth noting that the noticeable deviation of the reflection coefficients generated by different port inputs represents an important criterion for determining reconfigurable EPs in the real-time spoof plasmonic sensing system.

Figures 3(k)–3(o) depict the relation between the frequency splitting of DP and EP sensors and the perturbation strength on a logarithmic scale. The relation in DP sensors is validated by the slope of 1, confirming that conventional sensors are linearly correlated with the perturbation strength. Meanwhile, when the perturbation is adequately small (|Aj(2)|≫|ε|), EP sensors attract the frequency-splitting responses that demonstrate the slope of 1/2, which are proportional to ε1/2 and consistent with the prediction of Eq. (2). With respect to sensors operating at EPs, the frequency splitting produced by larger target particles gradually increases beyond the slope of 1/2 and even becomes comparable to that of DP sensors. This consequence arises from the fact that when the measured target is relatively large (|Aj(2)| is approximate to |ε|), Eq. (1) cannot be simplified to Eq. (2).

The histograms in Figs. 4(a)–4(e) illustrate the variations and comparisons of the frequency-splitting responses in DP and EP sensors when targets with different diameters are deposited near the resonator (see Sec. S5 in the Supplementary Material for detailed measured spectra). Note that the measurements were conducted 3 times under identical conditions, and the mean values of the three samples were used to represent the measured data. Remarkably, the light blue regions reveal that sensors working at EPs are capable of resolving smaller particles compared with DP sensors, validating their enhanced interactions with target particles. In addition, each EP sensor working at the corresponding plasmonic mode possesses a certain detectable range for targets of different dimensions. Experimental results indicate that modes of lower orders are capable of detecting larger particles. This is because lower frequencies correspond to longer wavelengths, which makes the resonator more suitable for detecting larger targets. In particular, the EP sensor operating at sextupole mode (M3) manifests the widest range of detectable particle sizes. The minimum target with the dimension of 0.001λ can be resolved in the 14-pole mode (M7). Furthermore, the prominent advantage of the proposed tunable and reconfigurable EP sensors is that they are capable of detecting particles much smaller than those detected by DP sensors across all five operating plasmonic modes. As the mode order increases, the minimum resolvable target size diminishes accordingly. It is demonstrated that the EP sensor working at M7 can identify a single target with a diameter of 0.1 mm, equivalent to the electrical length of 0.001λ (wavelength of the 14-pole mode).

The sensitivity enhancements |ΔωEP/ΔωDP|, which refer to the amplifications of frequency splitting in EP sensors compared to DP sensors, are illustrated in the insets of Figs. 4(a)–4(e). The dots in various colors represent the correlation between |ΔωEP/ΔωDP| and the perturbation strength ε acquired from the measurement, which conforms well to the fitted lines derived from Eq. (1). From the predicted fitting curves, we can estimate that when the target particle is small, the enhancements of all five EPs tend to be similar. However, the EP sensor working at the decapole mode (M5) exhibits the most enhanced sensitivity across the whole dimension range of targets. In particular, the dodecapole mode (M6) demonstrates the optimal sensitivity enhancement by the factor of 2.4 (frequency splitting with 3.74 MHz in the DP sensor enhanced to 8.86 MHz in the EP sensor). More details regarding the sensitivity enhancement are described in Sec. S6 in the Supplementary Material. Notably, the fluctuations between the experimental results and the fitting curves of the formula originate from tiny deviations generated by the manufacturing process and the instability of ambient temperature. In addition, the Q-factors of the reconfigurable EP sensors are scrupulously calculated by analyzing the transmission spectra, resulting in values of 136, 170, 200, 232, and 261 at each resonance mode, respectively. As depicted in Fig. 4(f), when the mode order increases, the corresponding Q-factor also exhibits an increase, and the minimum resolvable size of targets becomes smaller. Compared with previous EP-based WGM sensors in Table 2, our work achieves an unprecedented improvement in tunability and reconfigurability of EP sensing and extends the minimum resolvable limit of targets with high Q-values concurrently in a purely passive EP system.

In summary, we have proposed an experimental flexibly reconfigurable multimode EP sensor that capitalizes on the spoof plasmonic system coupled to two adjustable Rayleigh scatterers at microwave frequencies. Owing to strong field confinement at the boundaries of resonators, this novel sensor realizes five consecutive EPs in a broad range of frequencies and exhibits more than twofold sensitivity enhancement for the deep-subwavelength target detection. The range of detectable particle sizes is also widened. Meanwhile, our proposed sensors have two additional advantages: first, the tunability and flexibility of this system make it easy to realize EPs even in the presence of fabrication errors; second, compared with traditional ways based on frequency shift, the sensitivity of our proposed sensors depends on the frequency splitting; thus our system is highly robust.20^,22 Last but not least, our scheme not only can be transferred to other frequency bands (e.g., terahertz/infrared frequencies), as introduced in Sec. S7 in the Supplementary Material, but also inspire the future design of novel applications such as multichannel asymmetric transportation,13 reconfigurable topological lasers,14 and intelligent phononic metamaterials.42
