• Laser & Optoelectronics Progress
  • Vol. 61, Issue 23, 2301002 (2024)
Jinbo Wang1,2, Shiming Gao2,3,*, Zhi Liu4, Hongfei Song1,**, and Keyan Dong1
Author Affiliations
  • 1School of Optoelectronic Engineering, Changchun University of Science and Technology, Changchun 130022, Jilin , China
  • 2Centre for Optical and Electromagnetic Research, State Key Laboratory of Extreme Photonics and Instrumentation, Zhejiang University, Hangzhou 310058, Zhejiang , China
  • 3Ningbo Innovation Center, Zhejiang University, Ningbo 315100, Zhejiang , China
  • 4National and Local Joint Engineering Research Center of Space Optoelectronic Technology, Changchun University of Science and Technology, Changchun 130022, Jilin , China
  • show less
    DOI: 10.3788/LOP240692 Cite this Article Set citation alerts
    Jinbo Wang, Shiming Gao, Zhi Liu, Hongfei Song, Keyan Dong. Performance Evaluation and Uplink/Downlink Differences of Air-Ground Optical Communications in Non-Uniform Atmospheric Smoke Channels[J]. Laser & Optoelectronics Progress, 2024, 61(23): 2301002 Copy Citation Text show less

    Abstract

    A comprehensive channel model for air ground optical communication is established for an uneven atmospheric environment with smoke and fog, and a discrete layered height model is used to analyze the differences between uplink and downlink communication. Experimental results indicate that a stable simulation can be achieved after reaching six layers of high layering. In an uneven atmospheric smoke and fog environment, optical signs passing through smoke near the ground can significantly reduce communication quality, in which the effect on the downlink is greater than that on the uplink. In general, the performance of the uplink is superior to that of the downlink. An increase in the receiving aperture affects the performance improvement of the uplink more significantly than that of the downlink. As the receiving diameter increases by 0.1 m, the bit error rate decreases by an order of magnitude. Increasing the receiving aperture degrades the communication performance of the downlink. Meanwhile, increasing the zenith angle deteriorates the communication performance of both the uplink and downlink. The results of this study can provide theoretical reference for air ground laser communication.
    Jinbo Wang, Shiming Gao, Zhi Liu, Hongfei Song, Keyan Dong. Performance Evaluation and Uplink/Downlink Differences of Air-Ground Optical Communications in Non-Uniform Atmospheric Smoke Channels[J]. Laser & Optoelectronics Progress, 2024, 61(23): 2301002
