M. E. Kutepov1,*, V. E. Kaydashev1, D. V. Stryukov2, A. S. Konstantinov3..., A. S. Mikheykin3, A. V. Nikolskiy4, A. T. Kozakov4, A. D. Morozov5, M. A. Kashchenko5, G. V. Alymov5 and E. M. Kaidashev1|Show fewer author(s)
Author Affiliations
  • 1I. I. Vorovich Mathematics,Mechanics and Computer Science Institute,Laboratory of Nanomaterials,Southern Federal University,200/1 Stachki Avenue,344090 Rostov-on-Don,Russia
  • 2Federal Research Centre,The Southern Scientific Centre of the Russian Academy of Sciences,Chekhov Avenue,41,344006,Rostov-on-Don,Russia
  • 3Physics Faculty,Southern Federal University,5 Zorge Street,344090 Rostov-on-Don,Russia
  • 4Institute of Physics,Southern Federal University,194 Stachki Avenue,344090 Rostov-on-Don,Russia
  • 5Moscow Institute of Physics and Technology (MIPT),Institutskiy 9,141701 Dolgoprudny,Russia
  • show less
    DOI: 10.1142/S2010135X23400118 Cite this Article
    M. E. Kutepov, V. E. Kaydashev, D. V. Stryukov, A. S. Konstantinov, A. S. Mikheykin, A. V. Nikolskiy, A. T. Kozakov, A. D. Morozov, M. A. Kashchenko, G. V. Alymov, E. M. Kaidashev. Optimizing deposition regimes to fabricate VO2/TiO2/c-Al2O3 thin films for active metasurfaces[J]. Journal of Advanced Dielectrics, 2024, 14(6): 2340011 Copy Citation Text show less

    Abstract

    Decreasing the scale of vanadium dioxide (VO2) structures is one of the ways to enhance the switching speed of the material. We study the properties of VO2 films of altered thicknesses in the range of 20–170nm prepared on c-sapphire substrates with a TiO2 sublayer by pulsed laser deposition (PLD) method. The synthesis regime to design a TiO2 film was preliminarily optimized based on XRD data. XRD patterns reveal an epitaxial growth of the VO2 films with distortion of the monoclinic cell to hexagonal symmetry. The positions of the lattice vibration modes in Raman spectra are similar to those in bulk VO2 when the film thickness is greater than 30nm. For VO2 films thicker that 20nm,a lattice strain results in the modes’ positions and intensity change. However,the electrically triggered transition in a 50nm thick VO2 film reveals forward and reverse switching times as short as 20ns and 400ns,correspondingly.
    M. E. Kutepov, V. E. Kaydashev, D. V. Stryukov, A. S. Konstantinov, A. S. Mikheykin, A. V. Nikolskiy, A. T. Kozakov, A. D. Morozov, M. A. Kashchenko, G. V. Alymov, E. M. Kaidashev. Optimizing deposition regimes to fabricate VO2/TiO2/c-Al2O3 thin films for active metasurfaces[J]. Journal of Advanced Dielectrics, 2024, 14(6): 2340011
