• Journal of Inorganic Materials
  • Vol. 39, Issue 9, 1013 (2024)
Daoxiang XUN1, Xuwei LUO1, Mingran ZHOU1, Jiale HE1..., Maojin RAN1,2, Zhiyi HU1,2 and Yu LI1,*|Show fewer author(s)
Author Affiliations
  • 11. State Key Laboratory of Advanced Technology for Materials Synthesis and Processing, Wuhan University of Technology, Wuhan 430070, China
  • 22. Nanostructure Research Centre (NRC), Wuhan University of Technology, Wuhan 430070, China
  • show less
    DOI: 10.15541/jim20240027 Cite this Article
    Daoxiang XUN, Xuwei LUO, Mingran ZHOU, Jiale HE, Maojin RAN, Zhiyi HU, Yu LI. ZIF-L Derived Nitrogen-doped Carbon Nanosheets/Carbon Cloth Self-supported Electrode for Lithium-selenium Battery[J]. Journal of Inorganic Materials, 2024, 39(9): 1013 Copy Citation Text show less

    Abstract

    Selenium (Se) is considered as a new generation energy storage material of lithium-selenium (Li-Se) battery due to its high volume specific capacity (3253 mAh·cm-3) and high electronic conductivity (1×10-5 S·m-1). To address the problems of volume expansion, fast capacity decay, and low utilization of active materials during its charging-discharging process, a ZIF-L derived nitrogen-doped nanosheets/selenium (Se@NC/CC) flexible self-supported composite electrode is designed in this study for lithium-selenium battery by growing two-dimensional zinc-based metallic organic framework (ZIF-L) on carbon cloth (CC). The rich microporous structure in the nitrogen-doped carbon nanosheets can effectively alleviate the volume expansion during the reaction process, and the doping of heteroatoms N helps to adsorb Li2Se and reduce the loss of active substances. In particular, it is found that there is strong chemical bonding between Se and C in the Se@NC/CC electrode, which also helps to reduce the loss of active materials and improve the performance. Electrochemical results show that the initial discharge specific capacity of the Se@NC/CC electrode is 574 mAh·g-1 at a current density of 0.5C (1.0C=675 mAh·g-1), demonstrating a high initial discharge specific capacity. At a current density of 2.0C, the initial discharge specific capacity is 453.3 mAh·g-1, which maintains at 406.2 mAh·g-1 after cycling for 500 cycles and it also displays excellent rate performance compared to literature. Such a flexible self-supported selenium cathode designed in this study provides a new research route on the design of selenium host materials for advanced alkali metal-selenium batteries.
    Daoxiang XUN, Xuwei LUO, Mingran ZHOU, Jiale HE, Maojin RAN, Zhiyi HU, Yu LI. ZIF-L Derived Nitrogen-doped Carbon Nanosheets/Carbon Cloth Self-supported Electrode for Lithium-selenium Battery[J]. Journal of Inorganic Materials, 2024, 39(9): 1013
