• Optics and Precision Engineering
  • Vol. 33, Issue 3, 402 (2025)
Bo XUE1,2, Lijun ZHU1,2, Xing SU1,2,*, Li CHEN1,2..., Tao ZHOU1,2, Jianfei ZHANG1,2, Kuo HAI1,2,* and Wen HUANG1,2|Show fewer author(s)
Author Affiliations
  • 1College of Mechanical and Electrical Engineering, Northeast Forestry University, Harbin50040, China
  • 2Sichuan Precision and Ultra-Precision Machining Engineering Technology Center, Chengdu61000,China
  • show less
    DOI: 10.37188/OPE.20253303.0402 Cite this Article
    Bo XUE, Lijun ZHU, Xing SU, Li CHEN, Tao ZHOU, Jianfei ZHANG, Kuo HAI, Wen HUANG. Magnetorheological elastomer uniform polishing method for shell components[J]. Optics and Precision Engineering, 2025, 33(3): 402 Copy Citation Text show less

    Abstract

    This study introduces a novel uniform polishing method for the ultra-precision finishing of the inner surfaces of thin-shell components, based on the principles of magnetorheological elastomer (MRE) polishing. The methodology involves the application of a magnetic field to the outer surface of the component, enabling precise control of the MRE pressure on the inner surface, thereby facilitating uniform polishing. Magneto-elastic coupling simulations of the MRE were conducted using COMSOL Multiphysics software to determine the polishing pressure, its distribution across the component surface, and the velocity distribution within the polishing area. A material removal function model was developed based on the Preston equation, which was subsequently discretized and sampled to derive the material removal vector. The residence time at each point in the polishing area was calculated using the non-negative least squares method. To validate the proposed approach, a polishing experiment was conducted under a magnetic field of 0.32 T, utilizing a magnetorheological MRE device to polish a fused quartz glass workpiece measuring 60 mm × 60 mm × 1 mm for a duration of 78 minutes. The experimental results indicated that controlling the residence time at each point achieved an average material removal depth of 84.4 nm, with a fluctuation range of 10.9%, thereby attaining a uniform surface finish. These findings substantiate the effectiveness of the proposed method in achieving uniform polishing of the inner surfaces of thin-shell components.
    Bo XUE, Lijun ZHU, Xing SU, Li CHEN, Tao ZHOU, Jianfei ZHANG, Kuo HAI, Wen HUANG. Magnetorheological elastomer uniform polishing method for shell components[J]. Optics and Precision Engineering, 2025, 33(3): 402
