1 Introduction
Coherent light sources at the deep ultraviolet (DUV) region are important to the applications of lithography, defect inspection, metrology, and spectroscopy.1
The common way to build a DUV source based on solid-state laser is through multistage frequency conversion from the near-infrared, with solid or fiber lasers as pump sources. First, the advancement of high-power solid-state lasers, such as thin-disk lasers, single-crystal fiber (SCF) lasers, Ti:sapphire lasers, and fiber lasers, enables the pump sources to compensate for the energy loss during frequency conversion processes and obtain bright DUV light.8
Aside from the pump laser, the choice of nonlinear optical crystal is also important for improving the reliability, ease of use, and the lowering of costs for wider adoption in the industry. Three of the most popular nonlinear optical crystals for DUV generation are (BBO), (LBO), and (CLBO) crystals.17
Sign up for Advanced Photonics Nexus TOC. Get the latest issue of Advanced Photonics Nexus delivered right to you!Sign up now
Walk-off angle | Angular acceptance | ||
BBO | 110.60 | 2.400 | 0.10 |
CLBO | 38.95 | 0.992 | 0.32 |
LBO | 10.87 | 0.254 | 1.05 |
Table 1. Optical properties of BBO, CLBO, and LBO at 193 nm (1553.3 + 220.9 nm->193.4 nm, type I).
On the other hand, LBO25
In this paper, we demonstrate a narrow linewidth, nanosecond-pulsed laser at 193 nm based on two stages of cascaded SFG in LBO crystals. The pump light is generated from two actively synchronized pulsed lasers operating at 1030 and 1553 nm, respectively. The maximum output power at 193 and 221 nm is 60 and 220 mW, respectively. To the best of our knowledge, it is the highest average power ever reported for both 193- and 221-nm lasers by frequency mixing in LBO crystals. The conversion efficiency is 27% for 221 to 193 nm and 3% for 258 to 193 nm, which is the highest conversion efficiency ever reported using LBO. The 193-nm laser has a pulse duration of 4.6 ns and a repetition rate of 6 kHz, corresponding to a pulse energy of . The linewidth of a 193-nm laser is estimated to be (), which is the narrowest one from a solid-state pulsed laser using LBO crystal so far. These remarkable results confirm the viability of pumping LBO with solid-state lasers for reliable and effective generation of a narrow linewidth laser at 193 nm and unblock a new way to fabricate a cost-effective, high-power DUV laser system using LBO.
2 Experimental Setup
The overview of the experimental setup is shown in Fig. 1. Two synchronized homemade pulsed lasers operating at 1030 and 1553 nm are used as the fundamental sources. The 258-nm laser, produced from the FHG of the 1030-nm laser, serves as the pump light which, together with the 1553 nm light, generates the 193 nm in two cascaded SFG processes in the LBO crystal.
Figure 1.Experimental setup of the 193-nm laser system. SHG, second-harmonic generation; FHG, fourth-harmonic generation; SFG, sum frequency generation; DM1, AR@515 nm/HR@258 nm dichroic mirror; DM2: HR@258 nm/AR@1553 nm dichroic mirror.
The experimental scheme of the pulsed 1030-nm Yb-hybrid laser is shown in Fig. 2. A narrow linewidth () continuous-wave fiber laser at 1030 nm with 100 mW output power is intensity-modulated by an acoustic-optics modulator (AOM) to produce a pulse train of 96-kHz repetition rate and 15-ns pulse duration. To compensate for the power loss induced by the first AOM, the 0.3 mW pulsed laser light is preamplified to 30 mW by a single-mode fiber preamplifier and has its repetition rate decreased to 6 kHz via the second AOM, matching the repetition rate of the commercially available ArF excimer laser system. The timing signals of the two AOMs are synchronized by a digital delayer (DG645, Stanford Research Systems). The 6-kHz pulse train is amplified by another single-mode fiber preamplifier from 1 to 10 mW, to seed a 90 cm-long Yb-doped photonic crystal fiber (PCF) amplifier pumped by a 14 W multimode laser diode (LD) at 976 nm. With the boosted 800-mW laser power from the PCF amplifier, a Yb:YAG bulk crystal (atomic fraction of 2%, ) is inserted to be the final-stage main amplifier. The Yb:YAG bulk crystal is mounted in a water-cooled copper heat sink with the temperature regulated at 16°C and end-pumped by a 100 W multimode LD at 969 nm. The Yb:YAG bulk amplifier is built in a double-pass configuration to improve the gain and output power.
Figure 2.Experimental setup of the 1030 nm Yb-hybrid pulsed laser. AOM, acoustic-optics modulator; ISO, isolator; PCF, photonic crystal fiber; PBS, polarization beam splitter; QW, quarter-wave plate.
The 1553-nm laser constituting the other pillar for the SFG process is also developed in-house. A commercial continuous-wave DFB laser operating at the wavelength of 1553.3 nm with 12 mW output power is optically switched by a semiconductor optical amplifier. The generated pulsed laser is then amplified by three stages of Er-doped fiber amplifiers, and its output power reaches 600 mW with a pulse duration of 10 ns and linewidth of . Note that the switch signal of the semiconductor optical amplifier is also provided by the same DG645, ensuring that the pulse train is synchronized with that of the 258 nm laser. More details of this 1553 nm fiber laser system can be found in our previous paper.29
3 Results and Discussion
For the 1030 nm fundamental source, compared with the single-pass configuration, the double-pass configuration has an evident improvement in output power region, as shown in Fig. 3(a). The output power grows linearly as the pump power of 969 nm increases and shows no sign of saturation. With the double-pass configuration, the SCF amplifier provides a gain of nearly 8 and output power of 14.6 W with 100 W of pump light. The beam profiles of the 1030-nm laser output from the Yb:YAG bulk amplifier along propagation behind a lens of 200 mm focal length are measured via a CCD camera, as shown in Fig. 3(b). With Gaussian fitting, the beam quality factor in horizontal and vertical axes is calculated to be and 1.12, respectively. There are hardly any distortions to the excellent spot roundness, implying minimal thermal degradation in the Yb:YAG bulk.30 The pulse duration of the 14.6 W output is measured to be 13.1 ns, and the linewidth is measured by a scanning Fabry–Perot interferometer.
Figure 3.(a) Output power versus pump power in the Yb:YAG bulk crystal amplifier with single-pass and double-pass configurations; (b) the beam profiles of the 1030-nm laser output at 14.6 W of Yb:YAG bulk crystal.
For the ArF hybrid excimer laser, the SCF scheme offers advantages over the other schemes as the seed amplifier.4 Its compactness, including pumping with an LD, fits the dimension constraint of the traditional “twin chamber” or “chamber dual” ArF excimer laser system. Furthermore, it is more convenient and efficient for narrow linewidth laser amplification compared with fiber lasers in terms of exhibiting a higher stimulated Brillouin scattering threshold. Here, we demonstrate that the Yb:YAG bulk has exactly the same amplifier performance compared to that of SCF,5,16,17 showing the potential of leading to a more cost-effective DUV laser system.
With the pulsed laser of average power of 14.6 W at 1030 nm, 515 nm green light is produced by second-harmonic generation (SHG) within an LBO crystal (CASTECH) using a noncritical phase-matching (NCPM) scheme. The size of the LBO crystal is and it has an anti-reflection (AR) coating for 1030 and 515 nm on both ends. To meet the NCPM condition of the LBO, the crystal is held in a copper holder and heated to 185°C. Launching the 1030 nm beam with a diameter of , corresponding to a power density of nearly , the maximum generated output power and conversion efficiency for the 515 nm light reach nearly 10 W and 70%, respectively, as shown in Fig. 4(a). The generated 515 nm green light, with a pulse duration of , is separated from the 1030-nm light with two dichroic mirrors, with a high-reflection (HR) coating @ 515 nm and an AR coating @ 1030 nm. As there is no phase-matched angle in LBO crystal to generate 258 nm laser, BBO and CLBO become the two alternatives for FHG. Since the walk-off angle of BBO is 3 times larger than that of CLBO, a piece of CLBO crystal (, , , critical PM, CASTECH) is chosen for FHG. The CLBO crystal is placed in the Ar gas environment and heated to more than 150°C to prevent the hydroscopic reaction problem. To avoid laser-induced damage, both the input and output ends of the crystal are polished, while only the input end has an AR coating @ 515 nm. As shown in Fig. 4(b), the output highest average power of 258-nm laser is 2 W, corresponding to a conversion efficiency of only 20%, which is lower than that in previous reports.16,17,31 Actually, we could also obtain conversion efficiency at this stage in our setup. However, to protect the coating of the dichroic mirror DM1 (shown in Fig. 1), the highest power density of the 515 nm laser in the CLBO crystal is limited to about , which is also an optimization, as well as to mitigate the power degradation, commonly occurring in the nonlinear crystals.32 In other words, it is a trade-off between conversion efficiency and long-term operation. In addition, this trade-off will further benefit the conversion efficiency of the final SFG stage of the 193-nm laser.
Figure 4.Output average powers of (a) 515-nm laser and (b) 258-nm laser as the function of pump average powers of 1030 and 515 nm lasers, respectively.
As shown in Fig. 1, to generate the 193-nm laser, a 221-nm laser is first generated by SFG between the 258- and 1553-nm laser. Then, the 221- and the residual 1553-nm light exhibit the second SFG to output the final 193-nm laser. Normally, the two stages of SFG are separated, meaning the need for two specialized assemblies for each pump laser, which increases the complexity and cost of the system. To simplify the setup, the collinear cascaded scheme is introduced in our work including type-I and type-II PM schemes.19 For the first SFG, the LBO-1 crystal (, , , CASTECH) is chosen to generate a 221-nm laser, under type-II PM . For the second SFG, the LBO-2 crystal (, , , CASTECH) is chosen to generate the 193-nm laser, under type-I PM . The polarization of the 221 nm and the residual 1553 nm laser output from the first SFG satisfies the type-I PM condition of the second SFG. Consequently, two LBO crystals could be placed in tandem without additional polarization adjustments. Moreover, it is worth noting that the pulse trains of the 221 and the 1553 nm laser are also synchronized automatically in the second LBO crystal. To optimize the pump condition of the cascaded SFG process, the pump lasers should propagate with an adequately long Rayleigh length covering the two LBO crystals. This sets a minimum size for the focus spot and constrains the achievable power density. The spot waist diameters of the 258- and 1553-nm laser beams are regulated to 500 and , respectively, and the two beams are combined with dichroic mirror DM2. Before inserting the LBO-2 crystal, the 221-nm laser generated from the LBO-1 crystal is separated by a calcium fluoride () prism for diagnostics. With the 1553-nm pump power at 600 mW, a maximum output power of 220 mW but conversion efficiency only of 10.9% at 221 nm is obtained, lower than that of more than 20% at a low pump, as shown in Fig. 5(a). Two factors contribute to the efficiency reduction in this SFG stage: first, the focus power intensity of 258-nm laser is not optimized for 221-nm laser generation; second, the high-power pump laser beams’ size may change due to the thermal effect.9 Interestingly, after inserting the LBO-2 crystal following the LBO-1 for the second SFG stage, a laser power of 60 mW at 193 nm is generated corresponding to a conversion efficiency of 27%, as shown in Fig. 5(b). Hence, the total efficiency is for 258 to 193 nm. To date, 27% for 221 to 193 nm and 3% for 258 to 193 nm is the highest conversion efficiency ever reported using an LBO crystal.
Figure 5.Output average powers of (a) 221-nm laser and (b) 193-nm laser generated from the first and second SFG in LBO crystal as a function of pump average powers of 258 and 221 nm lasers, respectively.
According to the linewidth of 1030 nm () and 1553 nm laser (), the linewidth of the 193-nm laser is estimated to be , corresponding to an . The pulse energy is according to the repetition rate of 6 kHz. The pulse duration of the 193-nm laser is measured to be using a biplanar phototube, as shown in Fig. 6. The short pulse duration may result from the frequency uncertainty of the pump laser that would be transferred and even increased during the nonlinear frequency conversion, which leads to the linewidth broadening and pulse narrowing of the 193-nm laser. The inset in Fig. 6 shows the beam profile with an optical diameter of of the 193-nm laser in the far field measured by a pyroelectricity camera (Ophir Pyrocam III HR). Due to the small walk-off angle in LBO crystals, the 193 nm laser inherits excellent beam quality from the pump lasers. To measure the beam quality of the UV/DUV laser, a scanning-slit beam profiler (NS2s-PYRO/9/5-STD, Ophir) is employed to record the beam diameter variation along the propagation direction, with minimum measurable beam of , overcoming the resolution limitations of the pyroelectricity camera. Using the beam profiler, the laser beam quality of 258 nm is measured to be 1.24 and 1.18 in vertical and horizon directions, respectively, while the 221-nm laser obtained values of 1.29 and 1.21. Due to the limited sensitivity of the scanning-slit beam profiler, it is feasible to directly measure the beam quality of the generated 193-nm laser. However, since the SFG for the 193-nm laser is cascaded with that of the 221-nm laser and pumped by the 221-nm laser, it could be inferred that the 193-nm laser has almost an identical beam quality with the 221-nm laser.
Figure 6.(a) Pulse duration of the generated 193 nm laser. Inset: Beam profile of the 193-nm laser. Measured beam profiles of (b) the 258-nm laser and (c) the 221-nm laser.
The power stability of the 193-nm laser within 1500 s is shown in Fig. 7. During the first 1000 s, the output power has an obvious fluctuation and gradually degrades from 60 to nearly 40 mW. The fluctuation comes from the free-running pump lasers, as they operate without any power-locking scheme. Moreover, the LBO crystals for generating 221- and 193-nm lasers are mounted on clamps without any temperature control. The increased heat induced by the pump lasers brings the phase mismatching within the crystals, leading to severe power fluctuations. Therefore, when the crystals reach the heat balance, the 193-nm laser shows a more stable characteristic during the last 500 s, with an average power of 40 mW and stability of 6.26% rms. It is worth noting that the power would recover to 60 mW by finely adjusting the angle of the LBO crystal, which proves that power fluctuation results from phase mismatch in turn. We believe that the 193 nm laser could present a more optimistic behavior if the temperature controller for LBO crystals and power-locking systems are introduced.
Figure 7.Power stability of the free-running 193-nm laser within 1500 s.
4 Conclusion
We demonstrated a high-power, narrow linewidth 193-nm pulsed laser by cascaded frequency mixing in LBO crystals between an Er-doped fiber laser and a Yb-hybrid laser. A maximum average power of 60 mW at 193 nm with a 4.6 ns pulse duration is obtained at a repetition rate of 6 kHz, while maximum average power of 220 mW at 221 nm is also achieved. The conversion efficiency is 27% for 221 to 193 nm and 3% for 258 to 193 nm. To the best of our knowledge, it not only achieves the highest average power ever reported for both 193- and 221-nm lasers by SFG using an LBO crystal but also demonstrated the highest DUV conversion efficiency recorded by an LBO. The 193-nm laser has a linewidth of , which is the narrowest obtained so far using frequency mixing in LBO, and a nearly circular beam profile in the far field. The output is suitable for seeding ArF excimer amplifiers to generate highly coherent DUV for lithography. In addition, although the LBO has a smaller nonlinear coefficient in the DUV region compared to others, it could be grown and cut to an impressive large dimension33 while still maintaining a low cost, which allows for compensation through a longer interaction length. This paves a new way for further power scaling up of a cost-effective DUV laser system by the use of LBO crystals in the future.
