Experimental implementation of phase triplicator gratings in a spatial light modulator

Shang Gao; María del Mar Sánchez-López; Ignacio Moreno

doi:10.3788/COL202422.020501

Abstract

In this work, we compare different methods for implementing a triplicator, a phase grating that generates three equi-intense diffraction orders. The design with optimal efficiency features a continuous phase profile, which cannot be easily reproduced, and is typically affected by quantization. We compare its performance with binary and sinusoidal phase profiles. We also analyze the effect of quantizing the phase levels. Finally, a random approach is adopted to eliminate the additional harmonic orders. In all cases, a liquid-crystal-on-silicon spatial light modulator is employed to experimentally verify and compare the different approaches.

Keywords

diffraction gratings phase modulation spatial light modulators triplicator

1. Introduction

Diffraction gratings of evenly distributed intensity among a number of diffraction orders, also called fan-out elements, are interesting for developing beam splitters and optical array illuminators. They were developed by the end of the 20th century, when the emergence of micro-optics technology made their fabrication possible^[1]. One popular initial approach was the Dammann grating^[2], which has a binary phase profile where the period is divided into different transition points^[3]. Other approaches based on multilevel^[4] or continuous^[5] phase profiles were developed later.

One particular case is the triplicator, a $1 \times 3$ fan-out diffraction grating that produces three equi-intense diffraction orders. Gori et al.^[6] derived the analytical solution for the phase-only design with optimal diffraction efficiency that yields 92.6% of the light intensity in the 0th and $\pm 1$ st orders. However, this solution features a continuous phase profile, which is difficult to properly reproduce, and is typically affected by quantization effects, which become more relevant as the period of the gratings gets reduced. Nevertheless, optimal phase triplicator gratings have been demonstrated with spatial light modulators (SLMs)^[7], with geometric-phase metasurfaces^[8], and with structured liquid crystals^[9]. The optimal triplicator design has recently received renewed attention for applications in telecomunications^[10] and for the physical implementation of trifocal diffractive intraocular lenses^[11,12].

In this work, we investigate the optimum triplicator design and the effect of quantizing the phase levels. Theoretical and experimental results for different phase triplicator designs are presented, where we use a liquid-crystal-on-silicon (LCOS) SLM to experimentally verify their properties. We compare the optimum design with the binary phase profile, a very simple alternative that provides an efficiency of 86.4%, and with the sinusoidal profile, which reaches 90.0% efficiency. In addition, we present a random multiplexing approach with much less efficiency but free of unwanted higher-order harmonics that affect the former designs. Let us remark that we consider in all cases scalar triplicators, i.e., we do not consider vectorial diffraction gratings^[13,14], which can reach 100% efficiency but are polarization-sensitive.
