• Journal of Inorganic Materials
  • Vol. 40, Issue 3, 281 (2025)
Haojie MU1, Yuanjiang ZHANG1, Bin YU2, Xiumei FU2..., Shibin ZHOU2 and Xiaodong LI1,*|Show fewer author(s)
Author Affiliations
  • 11. Key Laboratory for Anisotropy and Texture of Materials (Ministry of Education), Research Center for Advanced Ceramic Materials, School of Materials Science and Engineering, Northeastern University, Shenyang 110819, China
  • 22. Chengdu Dongjun Laser Co., Ltd., Chengdu 611630, China
  • show less
    DOI: 10.15541/jim20240438 Cite this Article
    Haojie MU, Yuanjiang ZHANG, Bin YU, Xiumei FU, Shibin ZHOU, Xiaodong LI. Preparation and Properties of ZrO2 Doped Y2O3-MgO Nanocomposite Ceramics [J]. Journal of Inorganic Materials, 2025, 40(3): 281 Copy Citation Text show less

    Abstract

    Compared with single-phase Y2O3 ceramics, Y2O3-MgO nanocomposite ceramics exhibit superior mechanical strength, hardness, thermal conductivity, and excellent infrared band transparency, endowing them a good infrared window material. However, harsh mechanical and thermal operating conditions impose stringent requirements on the optical and mechanical properties of infrared window materials. In this study, high-purity Y2O3-MgO nanocomposite powder was used as raw material, and Y2O3-MgO nanocomposite powders with different ZrO2 contents, in which Zr4+ ions accounted for the percentage of Y3+ ions at 1%, 3% and 5%, were prepared by adding zirconium nitrate aqueous solution during ball milling. ZrO2:Y2O3-MgO nanocomposite ceramics were fabricated by hot pressing sintering at 1350 ℃ and 35 MPa for 30 min. The influence of ZrO2 content on the phase, microstructure, infrared transmittance, hardness, and bending strength of nanocomposite ceramics was systematically studied. The results showed that doping ZrO2 dissolved and uniformly distributed in the Y2O3 lattice changed microstructure of Y2O3-MgO nanocomposite ceramics and caused lattice distortion, which had a significant impact on the optical and mechanical properties of Y2O3-MgO nanocomposite ceramics. The microstructures of ZrO2:Y2O3-MgO nanocomposite ceramics reveal that increasing ZrO2 content can hinder ceramic densification, resulting in obvious pores in 5%ZrO2:Y2O3-MgO nanocomposite ceramic. Meanwhile, doping ZrO2 can enhance the hardness and bending strength of Y2O3-MgO nanocomposite ceramics, which can be attributed to lattice distortion suppressing the dislocations’ motion. 3%ZrO2:Y2O3-MgO nanocomposite ceramic has a dense microstructure, with a transmittance of ~82% in the range of 3-5 μm, while exhibiting a hardness of 11.43 GPa and a bending strength of 276.67 MPa.
    Haojie MU, Yuanjiang ZHANG, Bin YU, Xiumei FU, Shibin ZHOU, Xiaodong LI. Preparation and Properties of ZrO2 Doped Y2O3-MgO Nanocomposite Ceramics [J]. Journal of Inorganic Materials, 2025, 40(3): 281
