• High Power Laser and Particle Beams
  • Vol. 36, Issue 7, 076002 (2024)
Tianyu Hui, Lili Tong*, and Xuewu Cao
Author Affiliations
  • School of Mechanical Engineering, Shanghai Jiao Tong University, Shanghai 200240, China
  • show less
    DOI: 10.11884/HPLPB202436.230408 Cite this Article
    Tianyu Hui, Lili Tong, Xuewu Cao. Simulation of coolant boiling phenomenon in sodium cooled fast reactor based on porous medium approach[J]. High Power Laser and Particle Beams, 2024, 36(7): 076002 Copy Citation Text show less

    Abstract

    Accurate prediction of the occurrence time and location of coolant boiling is of great significance for safety assessment of Sodium Cooled Fast Reactors (SFR). Based on a two fluid six equation model, conservation equations are constructed for the gas-liquid two-phase flow of sodium. The evaporation-condensation model is used to characterize the interphase mass exchange, and explicit and implicit methods are used to calculate evaporation-condensation model. Constitutive relationships such as Sobolev resistance model, two phase flow heat transfer model, and phase momentum exchange are considered. A porous medium analysis approach suitable for simulating SFR coolant boiling was developed, and comparative verification was conducted using KNS-37 L22 loss of flow experiment data. L29 flow data is used to verify the applicability of the model. The results indicate that the established sodium boiling porous medium analysis approach can effectively simulate the boiling phenomenon. It predicts that the boiling time will be around 6.3 s, which is 0.2 s different from the result of experiment. The overall trend of temperature and flow rate changes are in good agreement with the experimental data.
    Tianyu Hui, Lili Tong, Xuewu Cao. Simulation of coolant boiling phenomenon in sodium cooled fast reactor based on porous medium approach[J]. High Power Laser and Particle Beams, 2024, 36(7): 076002
