Abstract
1. Introduction
Long-distance light detection and ranging (Lidar) has attracted significant attention in military, astronomical, and civil fields. Frequency-modulated continuous-wave (FMCW) Lidar[1-3] has significant advantages in high-ranging accuracy, noise immunity, fast-moving target capture, and synchronous speed measurement, compared with other Lidar technologies such as phased array Lidar, time-of-flight Lidar, and pulsed-light Lidar[4-8]. These advantages allow the technique to enable applications such as three-dimensional (3D) object profiling[9-11], synthetic aperture imaging Lidar[12,13], noncontact precision metrology[14], and swept-source optical coherence tomography[15].
However, at considerably great target distances, or in certain special scenarios, such as deep-space and deep-sea applications[16,17], the reflected probe beam attenuates to the single-photon level. Although a higher power local oscillator improves the signal-to-noise ratio (SNR) of the beat signal[18], long-distance detection requires a detection system capable of broadband measurements, and the bandwidth and the sensitivity are incompatible features for a coherent heterodyne detector. Geiger-mode single-photon detectors have been applied to coherent detection to reduce laser power[19]. Furthermore, data acquisition is restricted by the Nyquist–Shannon sampling theorem[20]. The photon counting technique is utilized for frequency recovery of the beat signal[21,22]. The amount of data to be processed is time consuming and memory intensive.
Compressed sensing (CS) can recover the sparse signals with a sampling rate much lower than the Nyquist sampling rate, promising real-time, broadband signal detection[23-26]. Generally, random sensing matrices are usually used for CS since they satisfy the restricted isometry property with a high probability. For a one-round FMCW Lidar measurement, a single range with a round-trip delay produces a single-frequency beat signal, which meets the requirements of the signal sparsity of CS. The 1-bit CS is utilized to recover the frequency of the beat signal from the photon arrival sequence[27]. Although it works, the 1-bit quantization method is not fully applicable to photon detection-based situations. In fact, randomness is a fundamental property in quantum mechanics. The quantum compressed sensing (QCS) method realizes compressed sampling of sparse signals in the transform domain by preparing and detecting quantum state processes. In our previous work, a broadband (
Sign up for Chinese Optics Letters TOC. Get the latest issue of Chinese Optics Letters delivered right to you!Sign up now
In this work, FMCW Lidar working at the single-photon level is demonstrated based on QCS, in which the detection sensitivity, bandwidth, and compression ratio (CR) are improved significantly. In the single-photon FMCW Lidar, the interference at the single-photon level leads to the probability modulation of photon detection. The QCS constructs the CS using quantum physical processes, enabling us to recover target distances from the sparse photon sequence. The system is highly sensitive and capable of broadband measurement, which enables a large dynamic range and high-precision Lidar. Meanwhile, sub-Nyquist sampling significantly reduces the pressure of data storage and processing. In the experiment, a 3 GHz measurement bandwidth was realized with a photon count rate of kilo counts per second (kcps), and the CR improved by three orders of magnitude compared with that of the conventional coherent detection.
2. Compressive Single-Photon FMCW Laser Ranging
For the FMCW Lidar, the theoretical limit of the ranging resolution is inversely proportional to modulation bandwidth. However, laser phase noise and frequency nonlinear modulation can cause the spectrum of the beat signal to spread out during the actual measurement. Therefore, the ranging resolution is determined by considering both the modulation bandwidth and full width at half maximum (FWHM) of the spectrum of the beat signal[10].
Remote and high-precision FMCW Lidar requires discrete single-photon signals to recover the broadband beat signal, as shown in Fig. 1. QCS is a technology that constructs a CS system to realize data compression and broadband signal reconstruction based on quantum physical processes. In this study, the QCS includes two steps: random compressed sampling and information recovery.
Figure 1.Concept of the FMCW Lidar. (a) Schematic of the FMCW Lidar. (b) The compressed sampling of the random single-photon sequence. (c) The spectrum of the beat signal corresponding to the target distance is analyzed by the discrete Fourier transform (DFT). BS, beam splitter; FWHM, full width at half maximum.
For sampling in QCS, the beat signal
Compared with the traditional CS system, in which the mathematical model is expressed as
In quantum mechanics, the intrinsic randomness stems from the consumption of coherence, which appears as white noise in the frequency domain, as shown in Fig. 1(c). We denote
The quantum-mechanical operator of the beat signal is expressed as
Therefore, the output state of the beat signal is determined solely by the relative phase difference
For information recovery, the original beat signal
The FMCW Lidar working at the single-photon level has been noticed and studied by several research groups. The signal reconstruction methods of these works are mainly divided into two kinds. One is the photon counting method[21,22,35], which first recovers the waveform through photon statistics and then performs fast Fourier transform (FFT) on the recovered waveform. The second is to utilize the traditional CS 1-bit quantization model to achieve signal recovery[27]. This method introduces the idea of binarization on the basis of traditional CS, i.e., the sampling results are quantized into 1 bit by setting a threshold. In contrast, the QCS method proposed in this paper utilizes the inherent randomness of quantum coherence measurement to achieve compressive measurements of the physical quantity being measured.
3. Experimental Setup
The single-photon FMCW Lidar system is shown in Fig. 2. A narrow linewidth external cavity tunable 1550 nm laser (Toptica) was selected as the light source. Pound–Drever–Hall (PDH) locking technology was used to lock the laser frequency to the reference frequency provided by the ultra-stable cavity to ensure the stability of the output frequency[36]. Linear frequency modulation was achieved using an electro-optic modulator and radio-frequency signal generator. Subsequently, the modulated laser was split into a probe and reference beam by a BS.
Figure 2.The single-photon FMCW Lidar system. PID, proportional-integral-derivative; PZT, piezoelectric ceramic transducer; DC, direct current; AC, alternating current; FSG, function signal generator; CIR, circulator; PMC, polarization-maintaining coupler; PC, polarization controller; RF, radio frequency signal generator; EOM, electro-optic modulator; SLS cavity, ultra-stable cavity (SLS Company); OSC, oscilloscope; VOA, variable optical attenuator; PD, photoelectric detector; BS, 50/50 beam splitter; SPD, single-photon detector; TIA, time interval analyzer; AMP, amplifier; FSM, fast steering mirror.
The probe beam coherently interfered with the reference beam after covering a distance of 25 km. Here, the 25 km fiber is employed to emulate remote target detection, while simultaneously increasing the optical path difference between the signal light and reference light. This displacement effectively shifts the FMCW interference frequency from low to high frequencies, thereby circumventing low-frequency noise. An optical scanning system was added after 25 km fiber for 3D imaging. We first performed classical detection using a photodetector and a spectrum analyzer (ROHDE&SCHWARZ), combined with frequency locking to test the improvement in the ranging resolution. Furthermore, variable optical attenuators were used to simulate channel loss to the single-photon level. The beat signal was detected by a single-photon detector (IDQ230) with a high detection efficiency and low dark count rate, and the arrival time of each photon was recorded using a time interval analyzer (TIA, SIMINICS). The target distance was retrieved based on the post-processing QCS algorithm.
4. Experimental Results
By adding an optical scanning system to the system, targets at different positions are labeled with unique frequency shifts, and frequency mapping distance enables 3D reconstruction. In the experiment, the probe beam was coupled to the space through the 25 km fiber and illuminated the targets. Targets containing a plastic cube with a diameter of 2 cm, a regular hexagon, and an equilateral triangle with reflective tape were located at a distance of 1 m from the lens in the imaging system. The objects were separated by 5 and 7.5 cm as shown in Fig. 3(a). The optical scanning system consisted of a 4f system and a fast steering mirror to detect illuminated objects for reconstructing 57 pixel × 21 pixel resolution depth map and 3D imaging. Figure 3(b) shows the two-dimensional (2D) reconstruction from the frequency of the beat signal, and the 3D reconstruction of the target is shown in Fig. 3(c). To accelerate the imaging time, the dead time of the detector was set to 2 µs. The photon intensity of the reference path was maintained at 90 kcps, and the photon intensity of the probe path was collected at 50–110 kcps due to the different reflectivity of the objects. Two seconds of photon signals were accumulated on each pixel. The beat signal was averaged 8 times to improve the SNR. To ensure the SNR of the beat signal in single-photon coherent detection, the photon intensity of the reference and the signal paths should be equal. The optimal solution in scanning imaging is that the photon intensity of the reference path needs to be adaptively and optimally adjusted at each pixel point. We do not change the photon intensity of the reference path in our experiments, which is universal in real-world environments.
Figure 3.3D image of target. (a) The target containing multiple objects. (b) The 2D reconstruction. (c) The 3D image according to the frequency mapping distance.
4.1. Analysis of range resolution and accuracy
Since imaging resolution is related to frequency resolution, we investigated and analyzed factors that affect frequency resolution and accuracy, such as frequency modulation linearity, detection range, sweep rate, and bandwidth. Figures 4(a) and 4(b) show a comparison of the spectrum of the beat signal with and without frequency locking for the classical detection. The spectrum of the beat signal was measured with a linear frequency modulation sweep rate of 4 Hz and a sweep bandwidth of 3.3 GHz. The measured signals were averaged 200 times to improve the SNR. The phase noise of the free-running laser causes spectral broadening of the beat signal. The long-range transmission also introduces phase noise, which widens the FWHM of the spectrum of the beat signal to 65,844 Hz. However, the phase noise can be suppressed well, and the FWHM can be narrowed to 9.09 Hz with frequency locking. Accordingly, the frequency noise was suppressed by approximately 40 dB, which significantly improved the frequency resolution of the beat signal.
Figure 4.The spectrum of the beat signal when the laser is running freely and when the closed-loop frequency locking system is employed. The graph is centered on the frequency of 1,620,173 Hz. The black line is the experimental result and the red line is curve fitting. (a) Open-loop operation and classical detection. (b) Closed-loop operation and classical detection. (c) Single-photon detection and closed-loop operation.
The spectrum of the beat signal for the single-photon detection is shown in Fig. 4(c), with the spectral FWHM of 8.23 Hz by frequency locking. In this experiment, the mean photon count rate of the beat signal was
However, when fewer photons are detected, the quantum shot noise dominates, which appears as white noise in the frequency domain. Consequently, the SNR of the spectrum decreases. It is worth highlighting that the FWHM in single-photon detection is identical to that in classical detection. Clearly, QCS technology maintains the range resolution despite a reduction in the average photon count and enables high-precision long-range detection. Importantly, the 27 Hz shift in the peak signals of the classical and single-photon measurements is caused by the different reference clocks of the measuring instruments.
The relationship between the FWHM of the spectrum of the beat signal and the target distance with different sweep rates is shown in Fig. 5(a) for a sweep bandwidth of 3.3 GHz. We measured the beat signal at the range of 1–12.5 km, and added 20, 25, 30, 30.5, 32.5, and 40 cm to the 12.5 km optical fiber. As the fiber length is further expanded, phase noise caused by temperature drift and mechanical vibration cannot be ignored. The Doppler noise caused by the stress and strain of the fiber results in phase or frequency variations of the transmitted signal. The FWHM of the beat signal at a 12.5 km distance is nearly twice as large as that at a 1 km distance. Similarly, the FWHM of the beat signal exceeded 1 Hz at a sweep rate of 1 Hz owing to the phase noise of the system. After several measurements, the minimum of the FWHM of the beat signal is 2.18 Hz at a sweep rate of 1 Hz. In addition, when the sweep rate is 4 Hz, double peaks occasionally appear in the spectrum when the distance is 12.504 km, as shown in Fig. 5(b), owing to the frequency shift of the beat signal caused by the Doppler noise. The spectral SNR is reduced to 35.50 dB. The maximum of the FWHM of the spectrum is 8.83 Hz at a sweep rate of 4 Hz, and the corresponding ranging resolution is 6.69 cm, which is twice the theoretical limit of ranging resolution.
Figure 5.The ranging resolution and accuracy. (a) The FWHM of the spectrum of the beat signal with different target distances and different sweep rates. (b) The spectrum of the beat signal has double peaks because of the frequency shift of the beat signal caused by the Doppler noise of the fiber. (c) The relationship between the measured and theoretical distance increments. The linear fitting slope of the experimental data is 1.02.
To further illustrate the ranging resolution and accuracy of the system, the distance increments of 0.5, 2.5, 10, 20, 30, and 40 cm were used as shown in Fig. 5(c), with a sweep rate of 4 Hz and a sweep bandwidth of 3.3 GHz. The result shows that the deviations between the experimental and theoretical values are 1.05 and 0.23 cm when the distance shift is 2.5 and 5 cm, respectively. The experimental system could distinguish a distance increment of 5 cm. Error bars were obtained by taking multiple measurements of the frequency of the beat signal for each distance. The maximum value of the error bar is 0.28 Hz, indicating that the ranging accuracy of the system is 0.21 cm.
4.2. Noise immunity and broadband detection
FMCW Lidar is immune to ambient noise since the background noise photons are incoherent with the modulated beam. With the proposed QCS, our experiment shows that FMCW Lidar is also applicable at the single-photon level. In the experiment, an additional 1550 nm laser beam was added to the probe beam as background noise. The noise, probe, and reference beam photon count rate were all 6 kcps. Figure 6(a) shows a comparison of the spectra of the beat signals with and without background noise at a linear frequency modulation sweep rate of 1 Hz and a sweep bandwidth of 3.3 GHz; the frequency of the beat signal is 405,037.6 Hz, corresponding to the target distance of 12.53971 km. The signal and background noises can still be clearly distinguished, which can be attributed to the fact that the background noise without frequency modulation has the same power spectral density in each frequency component. The FWHM remains almost unchanged with and without the background noise. The spectral SNR is reduced from 41.30 to 38.54 dB due to the addition of background noise. A relatively higher
Figure 6.Noise immunity and broadband detection of our proposal. (a) Comparison of the spectra of the beat signals with and without background noise. (b) Test of broadband detection capability of our system from 200 MHz to 3 GHz based on QCS technology.
In the FMCW Lidar, the measurable bandwidth determines the range and resolution of the system. To demonstrate the broadband measurement capability of our system, the laser was frequency-modulated by applying signals of different frequencies to the electro-optic modulator. Photon detection and frequency demodulation were performed based on the QCS technique, and the results are shown in Fig. 6(b), where the frequency varies from 200 MHz to 3 GHz. The results show that the 3 dB bandwidth of the system is 1.43 GHz when the photon counting rate is approximately 6.8 kcps and the data compression rate reaches
5. Conclusion
In this study, FMCW Lidar working at the single-photon level is demonstrated based on QCS, in which the detection bandwidth and CR are improved significantly. QCS constructs the CS using quantum physical processes, enabling us to recover target distances from the discrete random single-photon sequence. Moreover, the system is highly sensitive and capable of broadband measurement, which enables a large dynamic range and high-precision Lidar. Meanwhile, sub-Nyquist sampling significantly reduces the data size and the pressure of data storage and processing. In the experiment, a 3 GHz measurement bandwidth was realized with a photon count rate of kcps, and the CR improved by three orders of magnitude compared with that of conventional coherent detection. To further improve the ranging resolution, the tunable laser was locked to an ultra-stable cavity using frequency locking technology, and the linewidth of the laser was narrowed to the Hz level, which overcomes the range limitation owing to the laser coherence length. Our proposal provides an idea for the application of QCS and solves the bottleneck problem of FMCW Lidar technology, which will greatly expand its applications in deep space, underwater, and harsh environments.
