• Infrared and Laser Engineering
  • Vol. 54, Issue 5, 20240484 (2025)
Junjie LI1,2,3,4, Xian RAN1,2,3,4, Nanfei YAN1,2,3,4, Dingkang TONG1,2..., Lanqiang ZHANG1,2,3,* and Changhui RAO1,2,3|Show fewer author(s)
Author Affiliations
  • 1National Laboratory on Adaptive Optics, Chengdu 610209, China
  • 2Institute of Optics and Electronics, Chinese Academy of Sciences, Chengdu 610209, China
  • 3University of Chinese Academy of Sciences, Beijing 100049, China
  • 4School of Electronic, Electrical and Communication Engineering, University of Chinese Academy of Sciences, Beijing 100049, China
  • show less
    DOI: 10.3788/IRLA20240484 Cite this Article
    Junjie LI, Xian RAN, Nanfei YAN, Dingkang TONG, Lanqiang ZHANG, Changhui RAO. Online aberration detection method of the high-altitude deformable mirror in multi-conjugate adaptive optics system[J]. Infrared and Laser Engineering, 2025, 54(5): 20240484 Copy Citation Text show less

    Abstract

    ObjectiveThe aberration of high-altitude deformable mirror (DM) in multi-conjugate adaptive optics (MCAO) system can lead to the decrease of the image contrast of the extended target and the decline of the closed-loop capability of the MCAO system. However, the aberration of the high-altitude DM in MCAO system is difficult to detect online due to its special conjugate position. The existing MCAO system usually requires regular removal of the high-altitude DM from the system for aberration detection and flattening. Some MCAO systems under construction may integrate interferometers in the optical path of high-altitude DM, but it is very challenging. So far, there is no simple way to detect high-altitude DM aberration online in MCAO system. Therefore, it is necessary to seek an online aberration detection method for high-altitude DM with certain accuracy. For this purpose, a multi-direction wavefront sensor based method is proposed.MethodsA multi-direction wavefront sensor can detect aberration information in different sub-area of a high-altitude DM from different line of sights. To retrieve the aberration of the entire high-altitude DM, it is necessary to detect wavefront in multiple directions. By using wavefront stitching method, the wavefronts detected by different line of sight directions should be concatenated in a certain position in order to obtain the complete wavefront information of the high-altitude DM.Results and DiscussionsNumerical simulation and experimental validation are carried out for the MCAO system parameters of the 1-meter new vacuum solar telescope at Yunnan Observatory. The detection capability of the proposed method for high-altitude DM is given (Fig.3). The relationship between the aberration detection accuracy and the conjugate height of deformation mirrors is also given, for the MCAO system of the telescope with 1 m aperture and 1' field of view, the proposed method has a lower error for the detection of deformed mirrors with 2 500-4 000 m conjugate height (Fig.5). Finally, the proposed method is used to online detect the aberration of 313-units DM of NVST MCAO system, and the detection error is 43.6 nm (Fig.9).ConclusionsThis article addresses the problem of difficulty in online detection of static aberrations of high-altitude DM in MCAO systems. An online aberration detection method based on pupil multi-direction wavefront sensor is proposed for a dual-conjugate adaptive optics system. Through theoretical and simulation analysis, it is found that the method has detection ability for deformation mirror aberration modes higher than the pupil detection order. However, there is also wavefront stitching error caused by inaccurate measurement of the pupil's Piston mode. In the experiment, the 7×7 sub aperture multi-direction Shack Hartmann wavefront sensor of the NVST MCAO system was used to detect aberration of a 313-units deformable mirror conjugated to 2.8 km. There is very small difference between the results of high-order self-collimated Shack Hartmann and the results of proposed method, which verified the correctness of the proposed method. Without additional detection devices, the proposed method can effectively reduce the static aberration of high-altitude DM, providing good closed-loop initial conditions for MCAO systems.
    Junjie LI, Xian RAN, Nanfei YAN, Dingkang TONG, Lanqiang ZHANG, Changhui RAO. Online aberration detection method of the high-altitude deformable mirror in multi-conjugate adaptive optics system[J]. Infrared and Laser Engineering, 2025, 54(5): 20240484
