• Journal of Inorganic Materials
  • Vol. 39, Issue 8, 895 (2024)
Jun CHENG1,2, Jiawei ZHANG1,2,*, Pengfei QIU1,2,3, Lidong CHEN1,2, and Xun SHI1,2,*
Author Affiliations
  • 11. State Key Laboratory of High Performance Ceramics and Superfine Microstructure, Shanghai Institute of Ceramics, Chinese Academy of Sciences, Shanghai 200050, China
  • 22. College of Materials Science and Opto-Electronic Technology, University of Chinese Academy of Sciences, Beijing 100049, China
  • 33. School of Chemistry and Materials Science, Hangzhou Institute for Advanced Study, University of Chinese Academy of Sciences, Hangzhou 310024, China
  • show less
    DOI: 10.15541/jim20240012 Cite this Article
    Jun CHENG, Jiawei ZHANG, Pengfei QIU, Lidong CHEN, Xun SHI. Preparation and Thermoelectric Transport Properties of P-doped β-FeSi2[J]. Journal of Inorganic Materials, 2024, 39(8): 895 Copy Citation Text show less

    Abstract

    β-FeSi2, an environmentally friendly and high temperature oxidation-resistant thermoelectric material, has potential applications in the field of industrial waste heat recovery. Previous studies have shown that phosphorus (P), an ideal n-type dopant in the silicon (Si) site of β-FeSi2, can easily lead to the formation of a secondary phase, thereby limiting the enhancement of thermoelectric performance. In this study, a series of FeSi2-xPx (x=0, 0.02, 0.04, 0.06) samples were synthesized using an induction melting method, which greatly inhibited the formation of the secondary phase. Then, the influence of P doping on the electrical and thermal transport properties of β-FeSi2 was studied. The results indicate that the solubility limit of P in β-FeSi2 is about 0.04, consistent with earlier theoretical predictions based on the defect formation energy. It is also discovered that P doping enhanced the thermoelectric performance of β-FeSi2, culminating in an optimal figure of merit (ZT) of FeSi1.96P0.04 approximately 0.12 at 850 K, which is much higher than the previous results (ZT about 0.03 at 673 K). However, compared to β-FeSi2 doped with other n-type elements like cobalt (Co) and iridium (Ir), which can achieve carrier concentrations up to 1022 cm-3, P-doped β-FeSi2 exhibits lower carrier concentrations, with the highest of only 1020 cm-3. This results in a weaker electron-phonon scattering effect, which in turn constrains the overall enhancement of the thermoelectric performance. If the carrier concentration could be further increased, the thermoelectric performance of the material is expected to evolve significantly.
    Jun CHENG, Jiawei ZHANG, Pengfei QIU, Lidong CHEN, Xun SHI. Preparation and Thermoelectric Transport Properties of P-doped β-FeSi2[J]. Journal of Inorganic Materials, 2024, 39(8): 895
