• Journal of Innovative Optical Health Sciences
  • Vol. 17, Issue 3, 2350033 (2024)
Lihua Ruan1、4, Zhiqin Yin1、2、3、4, Shibing Zhou1、4, Weibo Zheng1、4、*, Wei Lu1、2、3、4、5、6, Tao Zhang1、4、5、7, and Shaowei Wang1、2、3、4、**
Author Affiliations
  • 1Shanghai Institute of Technical Physics, Chinese Academy of Sciences Shanghai 200083, P. R. China
  • 2State Key Laboratory of Infrared Physics, Shanghai Institute of Technical Physics, Chinese Academy of Sciences, Shanghai 200083, P. R. China
  • 3Shanghai Engineering Research Center of Energy-Saving Coatings Shanghai 200083, P. R. China
  • 4University of Chinese Academy of Sciences, Beijing 100049, P. R. China
  • 5Shanghai Tech University, Shanghai 201210, P. R. China
  • 6School of Physical Science and Technology, ShanghaiTech University, Shanghai 201210, P. R. China
  • 7School of Information Science and Technology, ShanghaiTech University, Shanghai 201210, China
  • show less
    DOI: 10.1142/S1793545823500335 Cite this Article
    Lihua Ruan, Zhiqin Yin, Shibing Zhou, Weibo Zheng, Wei Lu, Tao Zhang, Shaowei Wang. Vein visualization enhancement by dual-wavelength phase-locked denoising technology[J]. Journal of Innovative Optical Health Sciences, 2024, 17(3): 2350033 Copy Citation Text show less

    Abstract

    Visual near-infrared imaging equipment has broad applications in various fields such as venipuncture, facial injections, and safety verification due to its noncontact, compact, and portable design. Currently, most studies utilize near-infrared single-wavelength for image acquisition of veins. However, many substances in the skin, including water, protein, and melanin can create significant background noise, which hinders accurate detection. In this paper, we developed a dual-wavelength imaging system with phase-locked denoising technology to acquire vein image. The signals in the effective region are compared by using the absorption valley and peak of hemoglobin at 700nm and 940nm, respectively. The phase-locked denoising algorithm is applied to decrease the noise and interference of complex surroundings from the images. The imaging results of the vein are successfully extracted in complex noise environment. It is demonstrated that the denoising effect on hand veins imaging can be improved with 57.3% by using our dual-wavelength phase-locked denoising technology. Consequently, this work proposes a novel approach for venous imaging with dual-wavelengths and phase-locked denoising algorithm to extract venous imaging results in complex noisy environment better.
    Lihua Ruan, Zhiqin Yin, Shibing Zhou, Weibo Zheng, Wei Lu, Tao Zhang, Shaowei Wang. Vein visualization enhancement by dual-wavelength phase-locked denoising technology[J]. Journal of Innovative Optical Health Sciences, 2024, 17(3): 2350033
