Laser frequency combs have impacted science and technology fields with their equidistant frequency spacings, serving as unique coherent clockwork.1^,2 Recent emerging applications include, for example, clocks for space-borne networks,3^,4 precise laser ranging metrology for autonomous platforms,5 and low-phase noise radio frequency generation,6^,7 all aided by low timing jitter mode-locked frequency combs. The observations of dissipative soliton microcombs in single microresonators8^,9 or coupled microresonators10 with smooth spectral profiles and dispersive waves11 offer opportunities to examine soliton comb dynamics in miniature platforms. There has been significant progress in soliton microcomb formation in different integrated microresonator platforms such as ${\mathrm{Si}}_3{\mathrm{N}}_4$,12 AlN,13${\mathrm{LiNbO}}_3$,14 and AlGaAs,15 benefiting from either ultrahigh quality factors or large nonlinear coefficients. The recent demonstrations of electrically pumped turn-key soliton microcombs16^–18 and mode-locked microcombs19 further reinforce the viability of the fully integrated frequency microcomb and pave the way for integrated functionalities such as terabit-per-second coherent transceivers,20^–22 parallel coherent LiDAR,23 astrophysical spectrographs,24^,25 laser spectroscopy,26^–28 distance ranging,29^–31 low-noise microwave generation,32^–34 and convolutional processing networks.35^,36

In soliton microcombs, the pump-resonance detuning noise37 plays a critical role in the pump-to-repetition–rate noise transduction.38^–40 A low repetition-rate phase noise (repetition-rate timing jitter) regime exists at a detuning where the soliton center frequency shift from dispersive-wave emission is balanced by nonlinear effects. The phase noise can be improved by injecting the locked pump laser into resonant cavities,19 by pumping the microresonators with a narrow linewidth laser,41 by optimizing high-order dispersion of the microresonators,42 and by thermal stabilization with an auxiliary laser.43 Quantum motion of the microresonators has also been observed recently through timing jitter characterization in counterpropagating soliton pairs after suppressing common-mode technical noise.44 With close-to-zero net group velocity dispersion (GVD), dispersion-managed soliton microcombs have been theoretically and experimentally investigated in active resonators featuring shorter pulse widths as well as better timing stability.44^–46 Therefore, the precise characterization of timing jitter in various microcombs is highly demanded. Direct photon detection can characterize timing jitter when repetition rates are detectable, but it has a limited timing jitter power spectral density (PSD) noise floor of $1\times {10}^{-6}{\mathrm{fs}}^2/\mathrm{Hz}$ at 1 MHz offset frequency.12 It is sensitive to intensity-noise-to-phase-noise (IM-PM) conversion.47 Linear fiber interferometry34^,48 could provide a lower timing jitter PSD noise floor of $1\times {10}^{-9}{\mathrm{fs}}^2/\mathrm{Hz}$, which is free of the IM-PM conversion and shot-noise limit.

Here, we demonstrated a series of thermally intracavity power-stabilized microcombs at different mode-locked states in 89 GHz dispersion-managed ${\mathrm{Si}}_3{\mathrm{N}}_4$ microresonators with negligible center frequency shifts and a broad frequency bandwidth. The demonstrated dispersion-managed (DM) microcombs not only expand the scope of soliton dynamics8^–11 but also enable low-jitter soliton trains. The DM microcombs suppressed occurrences of avoided-mode crossings (AMX),49^–51 compared with constant-dispersion microcombs, allowing lower timing jitter PSDs. Subsequently, we determine the intensity and timing fluctuations of the soliton microcombs at the single-soliton, multiple-soliton, and soliton crystal52 states. As microcomb oscillators have high repetition rates, low pulse energy, and high pulse background, we present a linear interferometry approach with tens of $\text{zeptosecond}/{\mathrm{Hz}}^{1/2}$ timing jitter resolution to characterize its jitter. We note that the approach in Refs. 34 and 48 is reference-free and independent of the repetition rate, expanding from prior silica microcomb34 and fiber comb studies48 to the 89 GHz pulse train timing jitter measurements of the silicon nitride DM microcombs. The measurement of the fundamental timing jitter is based on (1) time delay for the frequency discrimination and (2) optical carrier interference for optical phase discrimination. We observe a relative intensity noise (RIN) of $-153.2\mathrm{dB}/\mathrm{Hz}$ at 100 kHz offset, with a corresponding integrated RIN of 0.034% from 100 Hz to 10 MHz for the single-soliton microcomb. For the single-soliton microcomb, the quantum-noise–limited timing jitter PSD is determined as $0.4{\mathrm{as}}^2/\mathrm{Hz}$ for 100 kHz offset, with an integrated jitter of $1.7\mathrm{fs}\pm 0.07\mathrm{fs}$ from 10 kHz to 1 MHz. The integrated timing jitter from 10 kHz to 44.5 GHz Nyquist is $\approx 32.3\mathrm{fs}$.

The fabrication procedure of the microresonator starts with a $3\mu \mathrm{m}$ thick ${\mathrm{SiO}}_2$ layer that is first deposited via plasma-enhanced chemical vapor deposition (PECVD) on a $p$-type 8″ silicon wafer to serve as the undercladding oxide. An 800 nm silicon nitride is subsequently deposited via low-pressure chemical vapor deposition (LPCVD), and the resulting nitride layer is patterned by optimized 248 nm deep-ultraviolet lithography and etched down to the buried oxide cladding via an optimized reactive ion etch. The nitride microresonators are then overcladded with a $3\mu \mathrm{m}$ thick oxide layer, deposited initially with LPCVD for $0.5\mu \mathrm{m}$ and then with PECVD for $2.5\mu \mathrm{m}$.

After taking anomalous GVD and AMX into consideration, we have implemented the Ikeda method to obtain the roundtrip-varying nonmean-field microcomb dynamics and noise character written as $$\{\begin{array}{l}{E}_{m+1}(0,t)=\sqrt{T_c}{E}_{\text{in}}+\sqrt{1-T_c}{e}^{-i({\omega }_0-{\omega }_p)t_R}{E}_m(L_{\mathrm{cav}},t)\\ \frac{\partial {\tilde{E}}_m(z,\omega )}{\partial z}=-[\alpha -i\frac{{\beta }_2(z)}{2}{\omega }^2]{\tilde{E}}_m(z,\omega )+i\gamma (z){\tilde{E}}_m(z,\omega )\star \{\mathcal{F}[R(t^{\prime })]\times \mathcal{F}[|E_m(z,t){|}^2]\},\end{array}$$where $t_R$ is the roundtrip time, $z$ is the propagation distance within each cavity round trip, $t$ is the fast time, $E_m(z,t)$ is the intracavity electric field of the $m$’th roundtrip, the Fourier transform correspondence on the fast time is ${\tilde{E}}_m(z,\omega )$, $E_{\mathrm{in}}$ is the external pump field, $\alpha$ is the propagation loss, $T_c$ is the coupling strength, $L_{\mathrm{cav}}$ is the cavity length, $\delta =({\omega }_0-{\omega }_p)t_R$ is the pump-resonance detuning phase, and ${\beta }_2(z)$ is the second-order dispersion coefficient varying over the roundtrip position. Here, ${\beta }_2(z)$ is chosen from Fig. 1(b) ensuring the averaged ${\beta }_2$ is $-4.3{\mathrm{fs}}^2/\mathrm{mm}$, based on our experimental characterization. $\gamma (z)$ is the Kerr nonlinear coefficient varying over the roundtrip position. $R(t)$ is the nonlinear response function, including the Raman response function. To incorporate the avoided-mode crossing-induced frequency shift, an additional frequency shift ${\mathrm{\Delta }}_n$ is introduced to the $n$’th mode so that the mode frequency becomes ${\omega }_n={\omega }_0+D_{1}n+\frac{D_2{n}^2}{2}+{\mathrm{\Delta }}_n$. ${\mathrm{\Delta }}_n$ is determined by the empirical two-parameter model $\frac{{\mathrm{\Delta }}_n}{2\pi }=\frac{-a/2}{n-b-0.5}$, where $a$ is the maximum mode frequency shift and $n$ and $b$ are the mode number and mode number for the maximum mode frequency shift, respectively. The thermal effect is not considered in the simulation because of the dual-driven thermal balance and the thermoelectric cooler (TEC) module. From the cavity-mode dispersion characterization, the cavity-free spectral range $D_1/2\pi =88.52\mathrm{GHz}$. Furthermore, we estimate the maximum frequency shift to be $\frac{{\mathrm{\Delta }}_n}{2\pi }=130\mathrm{MHz}$ at 1581.5 nm determined by the spectral peak in the soliton microcomb optical spectrum. The estimated value is supported by comparing the simulated comb spectrum with the experimental result, which is in good qualitative agreement. A total of 2000 modes centered at the pump are incorporated into the model. The simulation starts with vacuum noise and runs for $1\times {10}^5$ roundtrips until the solution reaches a steady state.

To characterize the performance of the timing jitter, we introduced the thermal noise ${ϵ}_{\mathrm{\Theta }}$, shot noise ${ϵ}_s$, pumping laser’s intensity noise ${ϵ}_{\text{in}}$, and frequency noise ${ϵ}_{\omega }$ into our modeling. The dynamics can be represented as $$\{\begin{array}{l}{E}_{m+1}(0,t)=\sqrt{T_c}(E_{\text{in}+}{ϵ}_{\text{in}})+\sqrt{1-T_c}{e}^{-i({\omega }_0-{\omega }_{p-}{ϵ}_{\omega })t_R}{E}_m(L_{\mathrm{cav}},t)+{ϵ}_{\mathrm{s}}\\ \frac{\partial {\tilde{E}}_m(z,\omega )}{\partial z}=-[\alpha -i\frac{{\beta }_2(z)}{2}{\omega }^2-i{ϵ}_{\mathrm{\Theta }}]{\tilde{E}}_m(z,\omega )+i\gamma (z){\tilde{E}}_m(z,\omega )\star \{\mathcal{F}[R(t^{\prime })]\times \mathcal{F}[|E_m(z,t){|}^2]\}.\end{array}$$

All these noise sources are assumed proportional to the normal distribution. The standard derivations of ${ϵ}_{\text{in}}$ and ${ϵ}_{\omega }$ are determined by the laser’s RIN PSD and frequency noise PSD, respectively.53^,54 To extend simulated Fourier frequency range to kHz frequencies, we examine this for a total of $2^{24}$ roundtrips.

The filtered microcomb after removing the pump laser is measured by a photodetector (Thorlabs, Newton, New Jersey, United States, PDA10CF) with an optical power of $210\mu \mathrm{W}$. A multimeter and an oscilloscope monitor the DC voltage ($V_0$). A signal source analyzer (Keysight, Santa Rosa, California, United States, E5052B) records the voltage fluctuation PSD $S_{\mathrm{\Delta }I}(f)$. A home-built diffractive grating pair is used to select the comb lines for the timing jitter PSD measurement. We first optimize the noise floor of the self-heterodyne linear interferometer (SHLI) by improving the signal-to-noise ratio of the detected radio frequency (RF) signal at 100 MHz. Second, we minimize the relative delay time between the two optical comb lines (${\nu }_n=190.11\mathrm{THz}$, ${\nu }_m=192.55\mathrm{THz}$) and the power difference of the two arms of SHLI to enable the suppression of the common-mode noise. Third, we optimize the delay time for the soliton microcomb based on two criteria: the first is to maximize the timing jitter measurement sensitivity, and the second is to expand the measured Fourier offset frequency range. The fiber delay length is optimized to be 49 m. The detected RF powers at the output of the two photodetectors are 14 and 19 dBm.

Figure 1(a) shows the schematic illustration of the DM soliton microcomb formation in the tapered microresonator, which includes scanning electron microscope images of the stoichiometric silicon nitride microresonator with an outer radius of $261\mu \mathrm{m}$ and a thickness of 800 nm. The nitride waveguide width is continuously changed from 1 to $4\mu \mathrm{m}$ to finely tune group velocity dispersion and filter high-order transverse modes in the single-mode microresonator.52 GVD varies along the microresonator from $-55$ to $58{\mathrm{fs}}^2/\mathrm{mm}$ simulated with the finite-element analysis method, as shown in Fig. 1(b) after considering both geometric and material dispersion. Figure 1(c) shows the simulated GVD for various waveguide widths along with the cavity path-averaged GVD calculated via the relation ${\beta }_2=\int {\beta }_2(z)\mathrm{d}L/L_{\text{cavity}}$, where ${\beta }_2(z)$ is the GVD for the microresonator waveguide and $L_{\text{cavity}}$ is the cavity circumference.

The fundamental transverse-electric mode features a small anomalous path-averaged simulated GVD of $-3.51{\mathrm{fs}}^2/\mathrm{mm}$ at a pump wavelength of 1602 nm. The cavity GVD is experimentally characterized by swept-wavelength interferometry with only two AMX across the entire wavelength range for near single-mode operation. The measured free spectral range and GVD are $\sim 89\mathrm{GHz}$ and $-4.39{\mathrm{fs}}^2/\mathrm{mm}$, respectively, as shown in Fig. 1(d). These values deviate from the calculated dispersion due to factors such as fabrication imperfections, material inhomogeneity, and limitations in the accuracy of our measurement setup. The measured loaded and intrinsic quality factors are $1.8\times {10}^6$ and $3.4\times {10}^6$, respectively. Subsequently, we numerically examined the timing jitter PSD depending on different intrinsic cavity GVD, assuming no AMX, thermal, higher order dispersion, and Raman effects, as shown in Fig. 1(e). As the GVD decreases, the jitter PSD decreases. AMX will cause higher timing jitter PSD and higher integrated jitter accordingly, which will be proved in the numerical simulations, as shown in Fig. 1(f). These results show that the low-jitter pulse train can be realized by close-to-zero net dispersion and suppression of AMX. Our dispersion-managed adiabatic rings are able to suppress the occurrence of these avoided-mode crossings and obtain small dispersion, and thus reduce the timing jitter.

DM microcombs are subsequently generated in the microresonator. Figure 2(a) illustrates the optical spectrum of the single-soliton DM microcomb overlapped with the numerically modeled spectral profile. Modest spectral dips resulting from two hybridized interpolarization-mode couplings at 1592.64 and 1659.72 nm are observed. The 1563.64 nm peak is the auxiliary pump laser. The effect of the auxiliary pump diminishes once the soliton state is reached. To maintain stability, thermal noise needs to be actively controlled through feedback mechanisms. To illustrate the temporal performance of the microcomb, we measured the intensity autocorrelation trace with a noncollinear second-harmonic autocorrelator after pump suppression with a bandpass filter. Figure 2(b) shows the measured pulse width of the single-soliton at $\sim 305\mathrm{fs}$ for the filtered optical spectrum, along with the $\sim 11.2\mathrm{ps}$ pulse train. The modeled pulse width is included in the inset of Fig. 2(d). We also observed double-soliton and soliton crystal states in the microresonator. The corresponding measured optical spectra of the double-soliton and one-defect soliton crystal are illustrated in Figs. 2(e) and 2(g) overlapped by the modeled spectral profiles, respectively. The soliton crystal optical spectrum indicates destructive interference between a single-soliton microcomb and a 12 free spectral range (FSR) perfect soliton crystal microcomb. The spatiotemporal modeled intracavity waveforms are depicted in Figs. 2(f) and 2(h), where the soliton defect in the time domain is presented. The demonstrated microcombs offer broader optical spectra consistent with the simulated results over multiple soliton types with near single-mode operation with only two avoided-mode crossings and negligible center frequency shifts55 compared with prior studies.8^–19

To obtain the DM microcombs reliably and deterministically, Fig. 3(a) illustrates the implemented TE–TM dual-driven pump approach (more details in the Supplementary Material, Sec. I). The forward-propagating pump laser is amplified and polarized into the transverse-electric (TE) polarization, whereas the backward-propagating transverse-magnetic (TM) polarized auxiliary laser thermally stabilizes the microresonator intracavity total power. Through this approach, we generate the microcombs in a planar tapered dispersion-managed ${\mathrm{Si}}_3{\mathrm{N}}_4$ microresonator at the effective red-detuned region of resonance $v_{\mu }$ based on dynamic photothermal stabilization. The orthogonally polarized auxiliary laser is blue-detuned from the resonant mode $v_{\mu +53}$ in the reverse direction to mitigate thermal transients during the microcomb transition from a high-noise chaotic state to a low-noise mode-locked state and stabilize the pump-resonance detuning thermally. The TM-polarized auxiliary laser experiences normal GVD and avoids the initiation of parametric oscillation while also stabilizing intracavity power via optimization of power and phase detuning.43 To quantify the soliton microcomb noise performance, we conduct intensity noise at different soliton microcomb states prior to the respective timing jitter measurements. Coherence of the soliton frequency microcomb is examined via the RF intensity noise spectra over a microwave frequency span that is a few times the cold cavity resonance linewidth.

To supplement the RF intensity noise measurements of the soliton microcombs, measurement of the RIN is performed next. A signal source analyzer records the intensity fluctuation PSD of the soliton microcombs after suppressing the pump laser (detailed in Sec. 2). The filtered optical spectrum is shown in Fig. 3(b). The measured RIN PSD $[S_{\mathrm{RIN}}(f)]$ of the 89 GHz mode-locked microcombs, calculated by normalizing the measured intensity fluctuation PSD [$S_{\mathrm{\Delta }V}(f)$ in units of ${\mathrm{V}}^2/\mathrm{Hz}$] by the average detected intensity $|V_0{|}^2$, is shown in Figs. 3(c)–3(e) corresponding to the single-soliton, double-soliton, and one-defect soliton crystal microcombs. The black curves in Figs. 3(c)–3(e) are the RIN PSD of the spatiotemporal chaotic state53 (corresponding optical spectra are illustrated in the Supplementary Material, Sec. I, Fig. S1b2) and the pump laser, indicating the upper and lower bounds of the soliton microcomb RIN PSD. The soliton microcomb RIN PSD drops with a $30\mathrm{dB}/\text{decade}$ slope ($1/f^3$) over the first offset frequency decade, whereas the continuous-wave (CW) pump laser RIN PSD falls with a $20\mathrm{dB}/\text{decade}$ slope ($1/f^2$). The pump laser RIN PSD is measured at a nonresonant wavelength after the microresonator. The discrepancy between the two slopes is attributed to environmental noise sources such as free-space-to-chip coupling fluctuations. For the single-soliton state, the measured RIN is $-153.2\mathrm{dB}/\mathrm{Hz}$ at 100 kHz offset with a corresponding integrated RIN of 0.034% when integrated from 100 Hz to 10 MHz with the relation ${\mathrm{RIN}}_{\text{in}}={\int }_{f1}^{f2}{S}_{\mathrm{RIN}}(f)\mathrm{d}f$, where $f_1$ and $f_2$ are the lower and upper offset frequency bounds, respectively. The measured RIN of the double-soliton state and the soliton crystal state are $-149.8$ and $-148.6\mathrm{dB}/\mathrm{Hz}$, respectively, for a 100 kHz offset. The corresponding integrated RINs are 0.036% and 0.023% over the same integrated frequency range. The inset of Fig. 3(c) shows the electrical noise suppression to facilitate the observation of the dynamical intensity noise of the microcombs by optimizing the incident power of the photodetector from $-7.16$ to $-4.33\mathrm{dBm}$. The insets of Figs. 3(d) and 3(e) show the noise degradation of the double-soliton and soliton crystal microcombs, which results from the conversion of phase fluctuations to intensity fluctuations in the intracavity spectral interference process.

We next examine the timing jitter via an SHLI. Figure 4(a) illustrates the implemented SHLI architecture for precision timing jitter metrology. The interferometer consists of a reference arm and a time-delayed arm in which a fiber-coupled acousto-optic modulator driven by an RF signal $f_m$ allows heterodyne detection of phase fluctuation power spectral density [PSD, $S_{\phi }$ ($\mathrm{dB}{\mathrm{rad}}^2/\mathrm{Hz}$)]. A diffractive-grating–based narrowband filter pair selects two microcomb lines at frequencies ${\nu }_n=n\times f_R+f_{\mathrm{CEO}}$ and ${\nu }_m=m\times f_R+f_{\mathrm{CEO}}$, as illustrated in the inset of Fig. 4(a) separated by a $(m-n)\times f_R$ frequency difference, where $f_R$ is the repetition rate and $f_{\mathrm{CEO}}$ is the carrier-envelope offset frequency of the microcombs. Frequency noise $\mathrm{\Delta }\nu (f)$ of the selected lines is subsequently discriminated with the delay time $\tau$ by the relation $\mathrm{\Delta }\varphi (f)=2\pi \mathrm{\Delta }\nu (f)\tau$. The optical phase fluctuations $\mathrm{\Delta }\varphi (f)$ are converted into optical intensity fluctuations by linear optical interferometry. At the fiber interferometer output, the two optical lines are demodulated by two photodetectors. The residual phase noise PSD originates from the frequency difference $(m-n)\times f_R$ of the two selected comb lines, proportional to the delay time $\tau$. Then, a double-balanced mixer is used to extract the timing jitter PSD and eliminate the common-mode noise induced by the carrier-envelope offset signal and the driven microwave frequency signal ($f_m$). The frequency fluctuations of the two selected optical comb lines are converted into voltage fluctuations with the transfer function $\mathrm{\Delta }V(f)\propto K_{\phi }\frac{|1-e^{-i2\pi f\tau }|}{|i\times f|}(m-n)\mathrm{\Delta }{f}_R(f)$, where $K_{\phi }$ is the peak voltage at the double-balanced mixer output. The transfer function shows that the measured voltage fluctuation is proportional to $|1-e^{-i2\pi f\tau }|/|i\times f|$, which implies there will be null points at the offset frequency $f=1/\tau$ and its harmonics, providing the upper Fourier frequency limit of the timing jitter measurement.

The measured voltage fluctuation PSD is subsequently converted into frequency noise PSD and further into timing jitter PSD $S_{{\mathrm{\Delta }T}_R}(f)$ with the relation $S_{{\mathrm{\Delta }T}_R}(f)=(\frac{1}{2\pi f_R}{)}^2\frac{1}{(m-n{)}^2}\frac{1}{f^2}(\frac{|i\times f|}{K_{\phi }|1-e^{-i2\pi f\tau }|}{)}^2{\mathrm{S}}_{\mathrm{\Delta }V}(f)$. The detected voltage fluctuation at the mixer output is separated into two parts. The first part synchronizes the fiber interferometer to the frequency microcombs, avoiding free walk via a piezoelectric-transduced fiber stretcher (FS) through a loop filter with 1 kHz bandwidth. The second part is recorded by a signal source analyzer, which gives the timing fluctuation PSD and the frequency fluctuation PSD of the soliton microcomb repetition rate. To precisely remove the common-mode noise resulting from dispersion and increase the interferometer signal-to-noise ratio, we utilize a delay control unit, which contains a motorized fiber delay line and a pair of wavelength division multiplexing (WDM) couplers. This timing-stabilized and dispersion-compensated fiber interferometer can be considered a true time delay, which is an optical counterpart of the delay line frequency discriminator in microwave metrology.60

We convert the measured voltage fluctuation PSD on the baseband into the repetition-rate frequency noise $S_{\mathrm{\Delta }{f}_{\mathrm{R}}}$ PSD to examine the frequency noise behavior, as shown in Figs. 4(b1)–4(b3) of the soliton microcomb at the single-soliton, double-soliton, and soliton crystal states, respectively. The measured repetition-rate frequency noise PSD are 2556, 4151, and $4168{\mathrm{mHz}}^2/\mathrm{Hz}$, respectively, at 100 kHz offset with a noise frequency resolution of $64\mathrm{mHz}/{\mathrm{Hz}}^{1/2}$ at the single-soliton microcomb. We observe that the repetition-rate frequency noise features a 20 dB/decade slope below $\sim 20\mathrm{kHz}$ offset, indicating the repetition-rate random walk frequency noise. Based on the power-law noise, soliton microcombs have a repetition-rate flicker frequency walk from $\sim 20$ to 40 kHz offset, a white frequency noise from $\sim 40$ to 200 kHz offset, and a flicker and white phase noise from $\sim 200\mathrm{kHz}$ to 1 MHz. The resulting integrated linewidths of the free-running repetition-rate tone are shown in Fig. 4(b) for the three microcomb dynamical states. We also note that the repetition-rate close-to-carrier phase noise can be stabilized to a low-noise microwave oscillator.24

Figures 4(c1)–4(c3) show the measured timing jitter PSD for different soliton dynamical states. For the single-soliton comb, the measured quantum-noise–limited timing jitter PSD is $0.4{\mathrm{as}}^2/\mathrm{Hz}$ at 100 kHz offset. The corresponding integrated timing jitter is $1.7\mathrm{fs}\pm 0.07\mathrm{fs}$ when integrated from 10 kHz to 1 MHz, as shown in Fig. 4(c1), which is close to the timing jitter in silica microresonator frequency microcombs measured with similar technology.34 The integrated timing jitter from 10 kHz to 44.5 GHz Nyquist is $\sim 32.3\mathrm{fs}$. The achieved femtosecond-level jitter is enabled by close-to-zero intracavity dispersion to minimize group delay fluctuations, suppressed Kerr nonlinearities within the tapered waveguide,45 and the thermally stabilized dual-driven approach. Our dispersion-managed microresonator stretches the soliton pulse within the cavity, reducing the accumulated nonlinear phase shift during pulse propagation. The quantum-noise–limited timing jitter PSD of the two (double-soliton and soliton crystal) states at 100 kHz offset are at 0.66 and $0.82{\mathrm{as}}^2/\mathrm{Hz}$, respectively. This corresponds to an integrated jitter of $1.9\mathrm{fs}\pm 0.06\mathrm{fs}$ and $1.8\mathrm{fs}\pm 0.09\mathrm{fs}$. The dynamical noise is observed in the timing jitter PSD of the soliton crystal microcomb at the offset frequency of $\sim 8\mathrm{MHz}$. Compared with direct photon detection for timing jitter PSD measurements,12 the SHLI method can effectively avoid the IM-PM conversion and shot-noise limit. The measured timing jitter PSD is comparable to prior works,12^,34^,44^,57^,58 as shown in Fig. 4(c1).

For each of the microcomb soliton states, we observe that the timing jitter PSD drops with a $40\mathrm{dB}/\text{decade}$ slope within 3 to 20 kHz, as shown in Fig. 4(c). Deviation of timing jitter PSD over low Fourier frequency is associated with intracavity power fluctuation leading to a $1/f^4$ slope with the relation $S_{\mathrm{\Delta }{T}_R}^{T_R}(f)=(\frac{1}{2\pi f{T}_R}{)}^2{S}_{T_R}(f)$ where intracavity power-induced roundtrip fluctuations ${\mathrm{S}}_{T_R}\propto f^{-2}$.

Figure 4(c) also plots the theoretical cavity thermal bounds on the timing jitter PSD with the yellow solid line, arising from thermo-refractive variation and bounding the measured timing jitter PSD from 20 to 40 kHz with a $25\mathrm{dB}/\text{decade}$ slope ($1/f^{2.5}$). In the DM microresonator, the thermal-noise–limited timing jitter PSD, originating from the thermodynamic fluctuations $⟨\delta T^2⟩=k_B{T}^2/\mathrm{CV}\rho$, where $V$ is the optical mode volume, $k_B$ is the Boltzmann constant, $T$ is the chip temperature, $\rho$ is the density, and $C$ is the specific heat capacity, is described with the following model:61$$S_{{\mathrm{\Delta }T}_R}(f)=\frac{1}{(2\pi f_R{)}^2}{\left(\frac{v_c}{f_R}\frac{1}{n_0}\frac{dn}{dT}\right)}^2\frac{1}{f^2}\frac{k_B{T}^2}{\sqrt{2{\pi }^4\kappa \rho Cf}}\frac{1}{R\sqrt{d_r^2-d_z^2}}\frac{1}{[1+(2\pi f{\tau }_d{)}^{3/4}{]}^2},$$(1)where $dn/dT$ is the thermorefractive coefficient, $\kappa$ is the thermal conductivity, $R$ is the microresonator ring radius, $d_{r(z)}=\int {\mathrm{d}}_{r(z)}\mathrm{d}L/L_{\text{cavity}}$ is the half-width of the fundamental mode along the tapered DM microresonator, and ${\tau }_d=\frac{{\pi }^{1/3}}{4^{1/3}}\frac{\rho C}{\kappa }{d}_r^2$. From 40 to 600 kHz, the measured PSD falls with a quantum-noise–limited $20\mathrm{dB}/\text{decade}$ slope ($1/f^2$). The theoretical quantum-noise timing jitter limit without shot noise is shown in Fig. 4(c) with the orange solid lines following the model56$$S_{{\mathrm{\Delta }T}_R}(f)=\frac{1}{4\pi \sqrt{2}{f}_R^2}\sqrt{\frac{\gamma }{{\mathrm{\Delta }}_{0}D}}\frac{g}{{\gamma }^2}[\frac{1}{96}\frac{\gamma D}{{\mathrm{\Delta }}_0}\frac{{\gamma }^2}{f^2}+\frac{1}{24}{(1+\frac{{\pi }^2{f}^2}{{\gamma }^2})}^{-1}\frac{{\gamma }^2}{f^2}\frac{{\mathrm{\Delta }}_{0}D}{\gamma }],$$(2)where $\gamma$ is the half linewidth half height of the cavity resonance, $f_R$ is the repetition rate of the microcombs, $g=\frac{n_2}{n_0}\frac{\hslash {\omega }_c^{2}c}{V{n}_0}$ is the nonlinear gain coefficient, $n_0(n_2)$ is the refractive index (nonlinear index) of the nitride resonator, ${\omega }_c=2\pi v_c$, $v_c$ is the center frequency of the microcombs, $c$ is the light speed in vacuum, $D=-\frac{{\beta }_2{\omega }_R^{2}c}{\gamma n_0}$ is the normalized dispersion, and ${\mathrm{\Delta }}_0={\omega }_0-{\omega }_P$ is the resonance-pump detuning. Above 600 kHz, the measured PSD is limited to $8905{\mathrm{zs}}^2/\mathrm{Hz}$ by the SHLI spectral resolution.

Based on soliton theory, the quantum-noise–limited timing jitter PSD model, especially in the high offset frequency more than 10 kHz, can analytically predict noise behaviors for different mode-locked states via the relation ${\mathrm{S}}_{{\mathrm{\Delta }T}_R}(f)\approx 0.5294\frac{\xi }{(2\pi f{)}^2}\frac{h\nu }{E_p}\frac{{\alpha }_{\mathrm{tot}}}{T_R}{\tau }_p^2$,57 where $E_p\approx \frac{4\pi h\theta v_c}{D_1{\gamma }_c}\sqrt{2D_2{\mathrm{\Delta }}_0}$ is the intracavity pulse energy, $D_1/2/\pi$ is the cavity FSR, $D_2$ is related to the cavity GVD, $\theta$ is the transmission of the microresonator, ${\gamma }_c$ is the cubic nonlinearity parameter, ${\tau }_p\approx \frac{1}{D_1}\sqrt{\frac{D_2}{2{\mathrm{\Delta }}_0}}$ is the intracavity pulse duration,37$\xi$ and ${\alpha }_{\mathrm{tot}}$ are the spontaneous emission factor and cavity loss, respectively. For different soliton states, the quantum-noise–limited timing jitter PSD is inversely proportional to the resonance-pump detuning and proportional to square root of the cavity dispersion. The soliton microcomb center frequency fluctuation PSD ${\mathrm{S}}_{{\mathrm{\Delta }v}_c}(f)$ can also be converted into the timing jitter with the relation ${\mathrm{S}}_{{\mathrm{\Delta }T}_R}(f)\approx (\frac{D_2}{f{T}_R}{)}^2{\mathrm{S}}_{{\mathrm{\Delta }v}_c}(f)$, where $\mathrm{\Delta }{v}_c$ is the center frequency fluctuations induced by avoided-mode crossings,39^,40 odd-order dispersion,42 or Raman effects.55 In addition, the intracavity intensity fluctuations will introduce the extra timing jitter PSD with the relation of ${\mathrm{S}}_{{\mathrm{\Delta }T}_R}(f)=C\times (\eta P_{\text{in}}{)}^2(\frac{1}{f}{)}^2{S}_{\mathrm{RIN}}(f)$, where $\eta =d{f}_R/d{P}_{\text{in}}$ is the transduction factor, $P_{\text{in}}$ is the microresonator intracavity power, and $C$ is a constant.34^,43

We note our noise measurements of the frequency microcombs below the offset frequency of 20 kHz are still higher than the microresonator theoretical thermodynamical limits. This is attributed to the strong free-running intracavity power fluctuations and pump-resonance detuning noise. Further active stabilization of the intracavity power and pump-resonance detuning33^,40 can improve the timing jitter PSD at the low-offset frequency. By increasing the tapered waveguide width (increasing the effective resonant mode volume) and decreasing the cavity GVD, the jitter of the frequency DM microcomb oscillator can be improved to subfemtosecond timing imprecision.

In this study, the fundamental noise of dispersion-managed soliton microcombs without a restoring force is examined in detail. Dispersion-managed microcombs are deterministically and reliably generated with a TE–TM dual-driven thermally stabilized approach at the single-soliton, double-soliton, and soliton crystal regimes. The RIN is determined to be $-153.2\mathrm{dB}/\mathrm{Hz}$ at 100 kHz offset for the single-soliton state, with parameters bounded by the CW pump laser. The timing jitter PSD is $0.4{\mathrm{as}}^2/\mathrm{Hz}$ at 100 kHz offset, and the corresponding integrated timing jitter is $1.7\mathrm{fs}\pm 0.07\mathrm{fs}$ from 10 kHz to 1 MHz ($\approx 32.3\mathrm{fs}$ from 10 kHz to Nyquist 44.5 GHz). To the best of our knowledge, we achieved femtosecond timing jitter for the first time in dispersion-managed microcombs. The demonstrated results show that the dynamic noise for the double-soliton and soliton crystal in the RIN PSD is important to understand intracavity soliton dynamics, with the single-soliton state having the lowest jitter and with slight but quantifiable variations across different soliton states.

The primary noise source at low-offset frequencies is the fluctuation in effective cavity length, which arises from intracavity power fluctuations in the microresonator. In dispersion-managed microcombs, we observe negligible center frequency shifts, which helps to prevent noise conversion processes related to center frequency shifts. Future studies could explore how high-order dispersion in these microresonators facilitates additional noise coupling mechanisms. By implementing feedback to stabilize the pump laser’s intracavity power and frequency, the timing jitter of the dispersion-managed chip-scale soliton oscillator could be reduced to subfemtosecond levels. Furthermore, balancing factors such as detuning, nonlinearity, higher order dispersion, and avoided-mode crossing in the microresonator can further minimize timing jitter.
