• High Power Laser and Particle Beams
  • Vol. 37, Issue 1, 012001 (2025)
Mingyue Shi, Mingan Guo*, Ming Yan, Lu Liu..., Errui Zhou, Gang Li, Shaohua Yang, Jing Wang, Jitong Xin, Bodong Peng, Jizhen Zhao, Yuan Yuan, Quan Guo and Yan Song|Show fewer author(s)
Author Affiliations
  • National Key Laboratory of Intense Pulsed Radiation Simulation and Effect, Northwest Institute of Nuclear Technology, Xi’an 710024, China
  • show less
    DOI: 10.11884/HPLPB202537.240224 Cite this Article
    Mingyue Shi, Mingan Guo, Ming Yan, Lu Liu, Errui Zhou, Gang Li, Shaohua Yang, Jing Wang, Jitong Xin, Bodong Peng, Jizhen Zhao, Yuan Yuan, Quan Guo, Yan Song. Research on circuit for generating high voltage ramp signal in streak camera[J]. High Power Laser and Particle Beams, 2025, 37(1): 012001 Copy Citation Text show less

    Abstract

    To realize high voltage threshold, high linear slope, simple circuit and easy debugging of ramp signal from the scan control module of streak camera, utilizing the advantages of high voltage generated by switching discharge and good linearity of constant current charging slope, we designed a simple circuit to generate high voltage ramp signal. The circuit can adjust and optimize the slope and linear rate of the linear slope signal by adjusting the resistance. The experimental results show that the linear high voltage ramp signal generated by the circuit can provide a voltage of up to 1 700 V, the nonlinear precision of the ramp is less than 3%, and the scanning time is adjustable from 200 ns to 50 μs. Compared with the traditional high voltage ramp signal circuit, the circuit is simple in structure and convenient to debug, and the ramp time can be adjusted steplessly from nanoseconds to microseconds. This can effectively improve the scanning time accuracy of the fringe camera and effectively reduce problems such as circuit crosstalk.
    Mingyue Shi, Mingan Guo, Ming Yan, Lu Liu, Errui Zhou, Gang Li, Shaohua Yang, Jing Wang, Jitong Xin, Bodong Peng, Jizhen Zhao, Yuan Yuan, Quan Guo, Yan Song. Research on circuit for generating high voltage ramp signal in streak camera[J]. High Power Laser and Particle Beams, 2025, 37(1): 012001
