• Optics and Precision Engineering
  • Vol. 32, Issue 15, 2334 (2024)
Jiazheng WU1,2, Yang AN1, and Wei LI1,*
Author Affiliations
  • 1Changchun Institute of Optics, Fine Mechanics and Physics, Chinese Academy of Sciences, Changchun30033, China
  • 2University of Chinese Academy of Sciences, Beijing100049, China
  • show less
    DOI: 10.37188/OPE.20243215.2334 Cite this Article
    Jiazheng WU, Yang AN, Wei LI. Flexible ultrablack surface with high absorption performance[J]. Optics and Precision Engineering, 2024, 32(15): 2334 Copy Citation Text show less

    Abstract

    Ultrablack surfaces are vital in thermal radiation and other fields. This study introduces a cost-effective method to create ultrablack surfaces with broad spectral and high absorption traits using femtosecond laser and reverse molding technology. It investigates the impact of laser parameters on the morphology and size of copper surface microstructures, determining optimal parameters for periodic microstructure processing. The research develops a process flow that integrates secondary molds with black paint substrates, achieving a flexible ultrablack surface with high absorption across the solar spectrum. An innovative solar absorber design using the ultrablack surface and ITO transparent glass is tested through outdoor experiments. The results demonstrate absorption rates of up to 98.3% for normal incidence and over 90% at a 70° angle. The solar absorber with ITO glass can increase the device temperature by up to 4 ℃. The process is simple, cost-effective, and suitable for large-scale application due to its flexible substrate.
    Jiazheng WU, Yang AN, Wei LI. Flexible ultrablack surface with high absorption performance[J]. Optics and Precision Engineering, 2024, 32(15): 2334
