• Optical Instruments
  • Vol. 47, Issue 1, 41 (2025)
Xianyang TIAN1, Zexi ZHENG1,2,*, Huazhong XIANG1, Jiaqing TAO1, and Zhixian MEI1
Author Affiliations
  • 1Shanghai Engineering Research Center of Interventional Medical Device, University of Shanghai forScience and Technology, Shanghai 200093, China
  • 2School of Mechanical Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
  • show less
    DOI: 10.3969/j.issn.1005-5630.202401070002 Cite this Article
    Xianyang TIAN, Zexi ZHENG, Huazhong XIANG, Jiaqing TAO, Zhixian MEI. Continuous frame photography method based on Moire fringe technique for obtaining radial pulse waves[J]. Optical Instruments, 2025, 47(1): 41 Copy Citation Text show less

    Abstract

    The pulse is one of the important human physiological parameters, and the non-contact acquisition of pulse waves holds significant clinical application value. This paper proposes a method for amplifying the original vibration signal of the radial artery skin surface using Moire fringe technology under LED light, enabling the detection of pulse waves by recording the pulsation of the radial artery through continuous frame imaging. In the experiment, a striped thin film was adhered to the surface of the radial artery, and another set of stripes was placed 2~3 cm away from the artery formed Moire fringes under LED illumination. An industrial camera was used to continuously capture a sequence of images showing the periodic movement of the Moire fringes caused by radial artery pulsation. A region of interest was selected to extract the original pulse signal, which was then filtered using bandpass filtering and variational mode decomposition to obtain a pulse wave that preserved the detailed characteristics of the pulse. The results of measuring the pulse wave signals from multiple subjects demonstrate that this method can acquire complete pulse wave signals, retaining various features such as the primary wave, tidal wave, and dicrotic wave. The proposed method offers valuable reference for the non-contact acquisition of human pulse waves.
    Xianyang TIAN, Zexi ZHENG, Huazhong XIANG, Jiaqing TAO, Zhixian MEI. Continuous frame photography method based on Moire fringe technique for obtaining radial pulse waves[J]. Optical Instruments, 2025, 47(1): 41
