• Optical Instruments
  • Vol. 46, Issue 2, 77 (2024)
Yu HE1、2, Long CHEN1、2, Xiaonan HU1、2, and Haitao LUAN1、2、*
Author Affiliations
  • 1Institute of Photonic Chips, University of Shanghai for Science and Technology, Shanghai 200093, China
  • 2School of Optical-Electrical and Computer Engineering, University of Shanghai for Science and Technology, Shanghai 200093, China
  • show less
    DOI: 10.3969/j.issn.1005-5630.202303130056 Cite this Article
    Yu HE, Long CHEN, Xiaonan HU, Haitao LUAN. Laguerre-Gaussian beam recognition based on optical diffractive neural network[J]. Optical Instruments, 2024, 46(2): 77 Copy Citation Text show less

    Abstract

    Laguerre-Gaussian (LG) beams possess radial quantum number p in addition to orbital angular momentum (OAM) dimension, and thus LG beams can provide more physical degrees of freedom for applications such as optical communication and optical computing. However, the recognition accuracy of the LG beam pattern detection method, which is commonly used by interference and diffraction mechanisms, is significantly reduced when it is disturbed by atmospheric turbulence (AT), which limits its practical application. We propose a diffraction neural network (DNN)-based LG beam recognition method that achieves p in the range of 1-3. Even in the case of strong turbulence intensity and diffraction distance of 5 m, the recognition accuracy still reaches more than 95%. This DNN method can provide an effective way to accurately identify LG beam patterns, and has potential applications in high-capacity OAM communication and high-dimensional quantum information processing.
    Yu HE, Long CHEN, Xiaonan HU, Haitao LUAN. Laguerre-Gaussian beam recognition based on optical diffractive neural network[J]. Optical Instruments, 2024, 46(2): 77
    Download Citation
