• Advanced Fiber Materials
  • Vol. 6, Issue 4, 00405 (2024)
Chenlu Fan1, Yanping Liu1,2,*, and Yumei Zhang3,**
Author Affiliations
  • 1Engineering Research Center of Technical Textile, Ministry of Education, College of Textiles, Donghua University, Shanghai 201620, China
  • 2Engineering Research Center of Digitalized Textile and Fashion Technology, Ministry of Education, Shanghai 201620, China
  • 3State Key Laboratory for Modification of Fibers and Polymer Materials, College of Materials Science and Engineering, Donghua University, Shanghai 201620, China
  • show less
    DOI: 10.1007/s42765-024-00405-9 Cite this Article
    Chenlu Fan, Yanping Liu, Yumei Zhang. A Universal, Highly Sensitive and Seamlessly Integratable Textile Resistive Strain Sensor[J]. Advanced Fiber Materials, 2024, 6(4): 00405 Copy Citation Text show less

    Abstract

    Textile strain sensors capable of monitoring human physiological signals and activities have great potential in health monitoring and sports. However, fabricating sensors with a wide sensing range, high sensitivity, robustness, and the capability for seamless integration into apparel remains challenging. In this work, a textile resistive strain sensor (TRSS) fabricated by selectively inlaying a conductive yarn, that is covered with water-repellent and antioxidative acrylic/copper complex fibers, into a highly elastic substrate via an industrialized knitting process is proposed. The conductive yarn is folded and compactly stacked to sense strains by changing contact resistance through contact separation of adjacent yarn sections in stretching. Owing to this folded structure, the TRSS has a wide sensing range (0–70%), high sensitivity (maximum gauge factor GFmax = 1560), low detection limit (< 0.5%), long-term fatigue resistance over 4000 cycles, and it can be seamlessly integrated into and become a part of various smart apparel products. An elbow sleeve, a knee sleeve and a sock are demonstrated to effectively monitor and distinguish various human bending motions. The fabrication strategy paves a viable way for customizing high-performance strain sensors for developing novel wearable electronics and smart clothing to detect multimode human motions.
    Chenlu Fan, Yanping Liu, Yumei Zhang. A Universal, Highly Sensitive and Seamlessly Integratable Textile Resistive Strain Sensor[J]. Advanced Fiber Materials, 2024, 6(4): 00405
