• Journal of Applied Optics
  • Vol. 45, Issue 6, 1298 (2024)
Chao FU*, Shiyu WANG, Bingbin LI, and Lequn LI
Author Affiliations
  • School of Optoelectronic Engineering, Xidian University, Xi'an 710071, China
  • show less
    DOI: 10.5768/JAO202445.0607003 Cite this Article
    Chao FU, Shiyu WANG, Bingbin LI, Lequn LI. Influence of resonant cavity state on beam pointing stability of high-power Nd:YAG pulsed solid-state laser[J]. Journal of Applied Optics, 2024, 45(6): 1298 Copy Citation Text show less

    Abstract

    A numerical calculation model of laser light field considering thermal distribution and gain distribution was constructed to evaluate the beam pointing angle instability of high-power solid-state lasers. The influence of the detuning degree of the resonant cavity output mirror and the mirror on the beam pointing stability was analyzed. The cavity mirror rotation perturbation factor and the cavity mirror movement perturbation factor were defined to describe the degree of parallel detuning and coaxial detuning of the cavity mirror, respectively, and the perturbation factor, thermal effect modulation and gain modulation were introduced in the calculation of the resonant cavity light field. The influence of resonant cavity parameters on the beam pointing stability of high-power Nd:YAG solid-state laser under the condition of cavity mirror detuning was studied. When the pump power is 10 000 W, and the cavity mirror rotation perturbation factor and the cavity mirror movement perturbation factor changing in the range of 1×10?4~50×10?4 and 1×10?7~50×10?7, respectively, the fluctuation range of the root mean square value of laser beam pointing offset angle in the pump pulse time is 1×10?6 rad~5×10?3 rad.
    Chao FU, Shiyu WANG, Bingbin LI, Lequn LI. Influence of resonant cavity state on beam pointing stability of high-power Nd:YAG pulsed solid-state laser[J]. Journal of Applied Optics, 2024, 45(6): 1298
