    Xu Zheng, Jun Song, Bo Song, Lei Zhang, Shiyu Zhong, Yan Liu, Yuanjie Zhang, Yusheng Shi. Laser Powder Bed Fusion Process of NiTi Alloys for Orthopedic Implants and Their Superelastic Properties[J]. Chinese Journal of Lasers, 2025, 52(12): 1202302 Copy Citation Text show less

    Abstract

    Objective

    Bone tissue engineering is a crucial approach for treating bone defects. NiTi alloys are regarded as highly promising materials for bone tissue engineering due to their exceptional superelasticity, shape memory effect, high specific strength, excellent corrosion resistance, and biocompatibility. However, their further development is constrained by traditional fabrication methods. Laser powder bed fusion (LPBF) technology can precisely control the porosity, phase transition temperature, and comprehensive properties of NiTi alloys, providing a new approach for preparing NiTi alloy bone scaffolds. Based on the application requirements of bone implants, this study systematically investigates the phase transformation temperature, mechanical properties, and superelastic behavior of LPBF-fabricated NiTi alloys, aiming to provide a theoretical foundation for the development of LPBF-fabricated NiTi alloy bone implants.

    Methods

    In this study, near-equiatomic NiTi alloy powder (Ni atomic fraction of 50.8%) is fabricated using an LPBF system. During the printing process, a process window is established by varying the laser power (P of 190‒310 W) and scan speed (v of 900‒1300 mm/s) to produce NiTi alloy samples with dimensions of 8 mm×8 mm×8 mm. The density of the samples is measured using the Archimedes drainage method, and the phase transformation temperatures are determined using differential scanning calorimetry (DSC), with the results visualized in a contour map. Additionally, the phase composition and microstructural evolution are analyzed using X-ray diffraction (XRD) and electron backscatter diffraction (EBSD). The mechanical properties and superelastic behavior are evaluated through uniaxial tensile tests and cyclic loading-unloading experiments.

    Results and Discussions

    An analysis of the contour maps of phase transformation temperature and relative density shows that under a constant laser power of 250 W, the phase transformation temperature of the samples is slightly higher than body temperature (37 ℃). Additionally, under these conditions, the relative density exceeds 99.5%, meeting the requirements for both phase transformation temperature and relative density (Fig. 2). When the laser power is kept constant at 250 W, with increased scanning speed, the phase transition temperature first increases and then decreases (Fig. 3). Three groups of representative samples (samples 1#, 2#, and 3#, with scanning speeds of 900, 1100, and 1300 mm/s, respectively) are selected for subsequent research. As the scanning speed increases, the grain size of the columnar crystals gradually decreases, accompanied by an increase in grain boundaries. Consequently, the average value of the Kernel average misorientation (KAM) progressively increases, indicating higher dislocation density and more pronounced changes in crystal orientation (Fig. 5). As the scanning speed increases, the cooling rate accelerates, temperature gradient decreases, and interface velocity increases, promoting the formation of finer grains. Sample 2# exhibits the highest tensile strength (625.6 MPa) and yield strength (336.8 MPa), demonstrating the best overall mechanical performance. However, excessively high scanning speeds lead to the formation of a small amount of unmelted powder and pores during the melting process. These defects act as stress concentration points during tensile testing, initiating and propagating cracks at lower stress levels and ultimately causing premature fracture, thereby reducing both the tensile strength and elongation at break of the material (Figs. 6 and 7). During the cyclic tensile loading-unloading tests, after the first cycle, sample 1# exhibits the highest recovery strain (9.38%), while sample 2# shows the lowest total strain and recovery strain compared to the other two samples. However, sample 2# demonstrates the highest deformation recovery rate of 94.02%. By the 10th cycle, samples 2# and 3# exhibited the same deformation recovery rate (99.51%). Considering the overall cyclic recovery performance, sample 2# exhibits the best deformation recovery behavior and optimal superelasticity (Figs. 8 and 9). Under the same stress level, sample 2# experiences less dislocation slip and martensitic plastic deformation, but a higher proportion of stress-induced martensitic transformation occurs. This results in a higher superelastic recovery rate for sample 2# compared to the other two samples.

    Conclusions

    This study investigates the influence of laser power and scanning speed on the relative density and phase transition temperature of an LPBF-fabricated NiTi alloy. A process window for LPBF of the NiTi alloy is established, and a method for optimizing the relationship between density and phase transition temperature is proposed. In addition, the impacts of different scanning speeds on the microstructure, mechanical properties, and superelasticity are analyzed. The findings indicate that at a laser power of 250 W and scanning speeds ranging from 900 mm/s to 1300 mm/s, the printed NiTi alloy exhibits a relative density higher than 99.5%, and its austenitic transformation finish temperature is approximately 39 ℃, close to human body temperature. As the scanning speed increases, the transition temperature and relative density of the alloy first increase and then decrease, while the grain size is gradually refined. The average grain size decreases from 34.4 μm to 20.5 μm. Both B2 austenite phase and B19' martensite phase are observed in the NiTi alloy formed by LPBF, but the peak of B19' martensite phase is weak. When the scanning speed is 1100 mm/s, the alloy exhibits optimal mechanical properties, with a tensile strength of 625.6 MPa and fracture strain of 14.67%. At a scanning speed of 900 mm/s, the sample exhibits the highest recovery strain (9.38%), while a scanning speed of 1100 mm/s results in a higher deformation recovery rate (99.51%), with the deformation recovery rate reaching 94.02% during the first cycle of tensile testing, demonstrating optimal superelastic performance.
