• Optics and Precision Engineering
  • Vol. 32, Issue 18, 2783 (2024)
Guifang QIAO1,2,*, Chunhui GAO1, Xinyi JIANG1, Simin XU1, and Di LIU1
Author Affiliations
  • 1School of Automation, Nanjing Institute of Technology, Nanjing267, China
  • 2School of Instrument Science and Engineering, Southeast University, Nanjing10096, China
  • show less
    DOI: 10.37188/OPE.20243218.2783 Cite this Article
    Guifang QIAO, Chunhui GAO, Xinyi JIANG, Simin XU, Di LIU. Spatial error prediction method for industrial robot based on Support Vector Regression[J]. Optics and Precision Engineering, 2024, 32(18): 2783 Copy Citation Text show less

    Abstract

    The high-end intelligent manufacturing field has put forward higher requirements for the absolute pose accuracy of industrial robots in high-accuracy application scenarios. This paper investigated the improvement of robot accuracy performance based on Support Vector Regression (SVR). Kinematic modeling and error analysis were performed on the Staubli TX60 series industrial robot. A robot measurement experiment platform was established based on the Leica AT960 laser tracker, and a large number of spatial position points were measured. The SVR model was trained and optimized based on real data sets. The actual pose error of the robot is predicted by Support Vector Regression Model, which avoids the complicated error modeling in the model-based robot accuracy improvement method. The average position error and average attitude error of the robot are reduced from (0.706 1 mm,0.174 2°) to (0.055 6 mm,0.024 6°) before compensation, respectively, and the position error is reduced by 92.12% and the attitude error is reduced by 85.88%. Finally, the comparison with BP neural network, Elman neural network and traditional LM geometric parameter calibration method verified the effectiveness and balance of spatial error prediction based on SVR model in reducing robot position and attitude errors.
    Guifang QIAO, Chunhui GAO, Xinyi JIANG, Simin XU, Di LIU. Spatial error prediction method for industrial robot based on Support Vector Regression[J]. Optics and Precision Engineering, 2024, 32(18): 2783
