• Matter and Radiation at Extremes
  • Vol. 9, Issue 2, 024201 (2024)
E. G. Gelfer1、2、a), A. M. Fedotov3, O. Klimo1、4, and S. Weber1
Author Affiliations
  • 1Extreme Light Infrastructure ERIC, ELI Beamlines Facility, 25241 Dolní Br̆ez̆any, Czech Republic
  • 2HiLASE Centre, Institute of Physics of the Czech Academy of Sciences, 25241 Dolní Br̆ez̆any, Czech Republic
  • 3National Research Nuclear University MEPhI, Moscow 115409, Russia
  • 4FNSPE, Czech Technical University in Prague, 11519 Prague, Czech Republic
  • show less
    DOI: 10.1063/5.0174508 Cite this Article
    E. G. Gelfer, A. M. Fedotov, O. Klimo, S. Weber. Collective coherent emission of electrons in strong laser fields and perspective for hard x-ray lasers[J]. Matter and Radiation at Extremes, 2024, 9(2): 024201 Copy Citation Text show less

    Abstract

    Coherent motion of particles in a plasma can imprint itself on radiation. The recent advent of high-power lasers—allowing the nonlinear inverse Compton-scattering regime to be reached—has opened the possibility of looking at collective effects in laser–plasma interactions. Under certain conditions, the collective interaction of many electrons with a laser pulse can generate coherent radiation in the hard x-ray regime. This perspective paper explains the limitations under which such a regime might be attained.

    I. BACKGROUND

    In the last few decades, the development of lasers has followed two distinct directions. In one of these directions, scientists have pushed the limit to reach multi-petawatt (1015 W) short laser pulses on the basis of chirped-pulse amplification;1,2 in the other, efforts are under way to shorten the wavelength of the emitted radiation as much as possible.3,4 In his 2003 Nobel Prize speech, Ginzburg identified the gamma-ray laser as one of the challenges of the 21st century.5

    II. COLLECTIVE RADIATION EMISSION IN A STRONG LASER FIELD

    One of the possible sources of high-frequency radiation is emission by electrons interacting with a strong optical laser pulse (nonlinear Compton scattering, NCS). For a single particle, the spectrum of this radiation is well known.6,7 Naively, the radiation of N particles should simply be N times stronger. However, if the motion of the particles is strongly correlated, i.e., if the initial conditions for spatial location8,9 and velocity10 are close (meaning that the density of the particles is high and the temperature is low), then the radiated energy can be strongly enhanced due to coherency8 (see Fig. 1).

    Top: two electrons that are close to one another in a phase space and interact with a laser can radiate coherently. Bottom: spectrum of a large number (N) of electrons colliding with a laser pulse for various densities of electron bunch. Dashed magenta curve: spectrum without accounting for coherency (N times the single-particle spectrum). The dot-dashed red curve shows the dependence of the highest coherently enhanced frequency on the density. The surface combines coherent (to the left of the dashed red curve) and incoherent (to the right) spectra. Laser intensity 1019 W/cm2, electron energy 50 MeV.

    Figure 1.Top: two electrons that are close to one another in a phase space and interact with a laser can radiate coherently. Bottom: spectrum of a large number (N) of electrons colliding with a laser pulse for various densities of electron bunch. Dashed magenta curve: spectrum without accounting for coherency (N times the single-particle spectrum). The dot-dashed red curve shows the dependence of the highest coherently enhanced frequency on the density. The surface combines coherent (to the left of the dashed red curve) and incoherent (to the right) spectra. Laser intensity 1019 W/cm2, electron energy 50 MeV.

    Indeed, the energy of the emitted radiation in an external field at the classical limit is given by6dEkdk=jμ(k)jμ(k)4π2,where k is the radiation wave vector and j is the Fourier transform of the current 4-vector. For two emitting particles,|jμ|2=|j1μ|2+|j2μ|2incoherent term+2Re(j1μjμ2)interference term,and under certain conditions, the interference term can be as large as the incoherent term, increasing the radiated power by a factor of 2. These conditions for the particles’ initial displacement R were established in Ref. 8: R is inversely proportional to the emitted frequency ω, and it also depends on the particles’ initial energy and the intensity of the laser.

    For N particles, the number of incoherent terms scales as N, while the number of interference terms scales as N2. This means that the coherent enhancement of radiation for a macroscopic number of particles can be huge. Since R ∼ 1/ω, the lower frequencies are enhanced more strongly than the higher frequencies; i.e., the shape of the radiation spectrum (with respect to the single-particle spectrum) is substantially modified by the coherency (see Fig. 1). Note that since the average distance between the particles is defined by the density n, the spectrum is very sensitive to the density. This is revealed in two particular ways: first, the enhancement factor for each frequency is proportional to the density; second, the maximum frequency ωcoh, which is enhanced due to coherency, scales as ωcohn1/3.

    It is worth noting that despite “higher” frequencies being unaffected by coherency, the threshold ωcoh of coherently enhanced “low” frequencies can be quite high—up to tens (and in some conditions even hundreds) of keV, depending on the laser intensity and the particles’ initial energy.8 In particular, for a 50-MeV electron beam with a density of 1022 cm−3 and a laser intensity of 1019 W/cm2, the coherency threshold exceeds 1 keV (see Fig. 1), while a 10-keV coherency threshold is provided by an energy of 200 MeV and a solid density of 1023 cm−3.8

    Moreover, according to Ref. 8, the ratio of the energy of the coherently enhanced radiation to that of the incoherent radiation (for initially slow particles and a relativistically intense laser a0 ≫ 1) isEcohEincoh164π3nλL3a02,where a0 = eELλL/2πmc2 is the dimensionless laser amplitude (in which EL and λL are the laser’s electric-field amplitude and wavelength, −e and m are the electron charge and mass, and c is the speed of light), meaning that the total energy of the coherent part of the spectrum can be much higher than that of the incoherent part. Indeed, for solid-density electrons and an optical laser pulse, the factor nλL3 can be as high as 1011, and for a0 ∼ 102 (corresponding to an intensity I ∼ 1022 W/cm2), one obtains Ecoh/Eincoh104.

    III. CHALLENGES AND PROSPECTS

    Although the creation of a “graser” (gamma-ray laser) is not imminent, it is clear that possibilities do exist for generating coherent hard x-rays using collective effects in plasmas when interacting with a short and ultra-intense laser pulses in the infrared regime. Optimization of the interaction process allows the coherent and incoherent contributions of the radiation generated by nonlinear inverse Compton scattering to be influenced; partial control of the coherency is thus possible.

    Nevertheless, a number of important theoretical questions still remain, and these need to be addressed in subsequent refined research. First, the presented approach is purely classical, and for an accurate investigation of the emission at high frequencies, one has to develop a quantum approach with accounting for coherency. Second, the effect of the temperature of the particle ensemble should be taken into consideration. Third, when coherency is taken into account, the particles can radiate so strongly [see Eq. (3) and the discussion below] that even for a mildly relativistic bunch and a moderately intense laser (I ≳ 1018 W/cm2) this will modify their trajectories in the laser field (the radiation reaction effect6), which will in turn affect the radiation emission. Finally, for a detailed description of laser–electron-bunch collision—which is necessary for planning and interpretation of experiments—numerical simulations are required. Particle-in-cell simulations are very powerful tools for investigation of the interaction of a plasma with a short intense laser pulse. Developing an implementation of coherent photon emission in such simulations is a challenging but necessary step toward employing coherent NCS for the creation of a hard x-ray source.

    ACKNOWLEDGMENTS

    Acknowledgment. E.G.G. is grateful to M. Grech, A. Grassi, and A. Mironov from LULI (France) for fruitful discussions. The collaboration with LULI was supported by the Czech Academy of Sciences (Mobility Plus Project No. CNRS-23-12). A.M.F. was supported by the Russian Science Foundation (Grant No. 20-12-00077).

    E. G. Gelfer, A. M. Fedotov, O. Klimo, S. Weber. Collective coherent emission of electrons in strong laser fields and perspective for hard x-ray lasers[J]. Matter and Radiation at Extremes, 2024, 9(2): 024201
