Conventional cameras are renowned for their large imaging field of view (FOV) and unparalleled image quality. Due to the use of complex optical components for aberrations correction, it has a bulky architecture and faces the challenges of high-precision alignment. With the advancement of technology, the miniaturization, light weight, and portable cameras1^–3 are increasingly desired in autonomous driving, endoscopic medicine, and consumer electronics. Therefore, there is an urgent need for planar and high-performance optical components to implement wide FOV on-chip cameras.

Recently, metalenses composed of subwavelength artificial structures have garnered attention for their compactness, as potential alternatives to bulky and complex optical instruments.4^–9 The metalens exhibits superior optical performance due to its ability to precisely manipulate the incidence beam;10^–15 however, aberrations correction still remains a challenge, in particular for chromatic aberration and off-axis monochromatic aberration. To eliminate chromatic aberration, the dispersive propagation phase and dispersive-free geometric phase have been introduced to achieve broadband16^–19 and multiwavelength20^–22 achromatic metalenses. Due to the limitation of the group delay dispersion of meta-atoms, achromatic metalenses are usually implemented on the paraxial condition. In the off-axis case, a great deal of effort has been made to correct the off-axis monochromatic aberrations of the metalens. By introducing the ray-tracing method,23^–27 Fourier analysis,28 and metalens array,29 cascaded metalenses located on either side of the substrate23^–25 and single wide FOV metalens with an aperture26^,27 can correct off-axis monochromatic aberrations and achieve diffraction-limited imaging over a wide FOV. However, chromatic aberration correction, central bright speckle, and image quality improvement of wide FOV metalens in the off-axis case are rarely considered. Obviously, addressing the aforementioned issues of wide FOV metalenses that rely on the above existing methods remains a considerable challenge.

To improve the image quality of a metalens, traditional image restoration computational imaging methods2^,22^,30^–32 are introduced, and they usually recover images based on simple hypotheses or enhance images through multiple-image super-resolution.2^,22^,30 However, the factors influencing the imaging quality of current ultra-wide FOV metalenses are intricate, making it difficult to improve the imaging quality based on a single hypothesis. In recent years, several methods have been proposed to incorporate neural networks for improving the imaging quality of metalenses or diffractive optical elements, which use point spread functions (PSFs) to train models.33^–37 Unfortunately, single-wavelength ultra-wide FOV metalenses have complex PSF spatial variations in different incident angles at other non-designed wavelengths, which makes it fail to accurately model the imaging degradation by applying the above PSF method. Even worse, the central bright speckle indicates that there is inconsistency between the simulation data and the actual scene, which makes it more difficult to improve the imaging quality of ultra-wide FOV metalenses by the prior PSF method.

With the advancement of deep-learning38 research, transformer modules based on attention mechanisms have been developed and demonstrated to be effective in cutting-edge studies, such as AlphaFold2,39 GPT,40 and large image-text models. Compared to CNN networks constructed with local convolutional kernels, the multi-head self-attention mechanism enables the transformer module to effectively model long-range dependencies, which is conducive to better modeling of wide FOV metalenses’ non-focused diffusion spots and information expansion problems. It is expected that incorporating transformer methodology into wide FOV metalens imaging is a good choice to cope with more complex PSF spatial variations so as to largely improve the quality of imaging.

In this work, we demonstrate a highly miniaturized neural meta-camera in conjunction with an ultra-wide FOV metalens assembled on a CMOS image sensor. The proposed metalens has a full FOV of nearly 140 deg and achieves a diffraction-limited resolution of up to 1.55μm at the center of the image side. The volume of neural meta-camera is 9.07mm×9.07mm×1.57mm, which is integrated based on precision assembly platform.

Based on this meta-camera, we propose the knowledge-fused data-driven (KD) paradigm to address the image degradation problem. The KD paradigm is characterized by first initializing the transformer-based neural network using unsupervised PSF estimation, and then further fine-tuning the neural network using the data obtained from the meta-camera. In this way, a customized neural network can be trained to recover a range of imaging quality problems for the ultra-wide FOV metalens. The experiments on simple, cartoon, and complex scene images validate that our method solves the chromatic aberration, distortion, and central bright speckle of the meta-camera. Our work shows that the neural meta-camera can achieve ultra-wide FOV and full-color imaging, which is also difficult to obtain with conventional complex cameras.

Here, we demonstrate a miniature neural meta-camera for ultra-wide FOV and full-color imaging supported by a transformer-based image recovery neural network (Fig. 1). The network has a typical multiscale attention architecture and is trained under the guidance of the KD paradigm so as to improve the reconstructed image quality. As identified by yellow arrows in Fig. 1, the paradigm includes prior knowledge from simulated PSFs and data-driven measurements from the meta-camera, incorporating prior and measured dataset to initialize and fine-tune the network. On the other hand, the processing flow of the image recovery neural network follows the green arrows in Fig. 1. The images captured from the ultra-wide FOV meta-camera are reconstructed into ground-truth-like full-color images by the recovery neural network. With the help of the computility of the graphics processing units (GPUs), the model can conveniently repair the chromatic aberration, distortion, stray speckles, and background noise of the meta-camera.

Recently, some approaches have been proposed for aberration correction and fast design of metasurfaces, such as hyperbolic phase profile,12^–15 quadratic phase optimization based on ray tracing,25^–27 gradient-based local optimization,21 inverse design,41^–43 and combination of deep neural networks.33^–37^,41^–44 Here, in order to obtain ultra-wide FOV and accurate off-axis aberration correction on a CMOS image sensor plane [Fig. 2(a)], the phase profile of a 140 deg wide FOV metalens is optimized by the ray-tracing method.25^–27 Such a metalens is composed of a 220-μm-diameter aperture and a 1.54-mm-diameter metasurface that are located on both sides of a 0.7-mm-thick fused silica substrate, with an effective numerical aperture of 0.167 and an operating wavelength of 532 nm. The fact that the root mean square spot diagrams [right of Fig. 2(a)] on the sensor plane at different angles of incidence are all within the radius of Airy disks indicates the metalens’s diffraction-limited performance with negligible monochromatic aberrations. We further simulate the alphabet image to illustrate good imaging performance in the whole FOV with clearly distinguishable alphabet letters [Fig. S1(a) in the Supplemental Material].

The metasurface contains Si nanoposts with different diameters arranged in quadrilaterals and covered by a 1-μm-thickness silicon dioxide protective layer. The phase coverage of 2π can be well achieved in seven selected nanoposts, with the average of over 95% transmission at normal incidence and decreasing value in off-normal directions. Note that the phase will shift accordingly when the incidence light is oblique. See more details in angle-dependent phase and transmission maps by rigorous coupled wave analysis45 in Figs. S1(b) and S1(c) in the Supplemental Material. We emphasize the fact that the simulated modulation transfer function (MTF) curves of the metalens at different incident angles are very close to the diffraction limit case [Fig. 2(b)], demonstrating the effectiveness of the metalens for aberration correction over a wide full FOV. At different incidence angles, the simulated focusing efficiency of the metalens is 31.5% to 66.25% and decreases with the increase of incident angle due to the phase shift and nonuniform transmittance of nanoposts as the incident angle changes [Figs. S1(b) and S1(c) in the Supplemental Material].

The ultra-wide FOV metalens is fabricated by electron beam lithography and inductively coupled plasma-chemical vapor deposition. The aperture and metasurface are aligned through alignment marks patterned on both sides of a substrate (Fig. S2 in the Supplemental Material). Top-view scanning electron microscope (SEM) images of the fabricated metasurface highlight the excellent fabrication quality [Fig. 2(c)].

To evaluate the optical performance of the naked ultra-wide FOV metalens sample, we used an experimental setup that enables the metalens to focus a collimated light from different angles, and the focused spots to go into a rear microscopic system [Fig. S3(a) in the Supplemental Material]. One can see from Fig. 2(d) that the measured focal lengths (blue solid box) and the image heights (red solid box) are close to the simulations (dotted lines) from 0 deg to 70 deg at a center wavelength of 532±5nm. Note that the image height is defined as the offset position of focal PSFs from the optical axis center in the focal plane. The results show the capability of the metalens for a full FOV angular position, ensuring the accurate match between the metalens imaging plane and the CMOS image sensor. In addition, we compare the simulated and measured focal spots, full width at half-maximum values, and corresponding MTF curves of different incidence angles. More details can be found in Fig. S3 in the Supplemental Material.

To characterize the imaging resolution capability of the designed metalens, we use the measurement configuration shown in Fig. S4(a) in the Supplemental Material. The USAF 1951 resolution test chart is illuminated by the lamp with different narrowband filters, and the images can be captured by the microscopic system, including an objective lens, an adapter tube lens, and a CMOS sensor. The resolution test chart is fixed on the image plane, and the microscopic system moves along the optical axis to make the image clear. Figure 2(e) shows the projected images of the USAF 1951 resolution test chart at the angle of 0 deg and a center wavelength of 532 nm. The linewidth and gap in the vertical lines (yellow) and horizontal lines (orange) of element 3 in group 8 are clearly distinguished, and the corresponding contrast values are 35.9% and 37.5%, respectively [right side of Fig. 2(e)]. The contrast value is the ratio of the difference and sum of the maximum and minimum intensities. The contrast values are all above 20%, indicating that the resolution of the metalens in the center is 1.55μm close to the diffraction-limited resolution (λ/2NA). The resolution results at wavelengths ranging from 488 to 680 nm are also shown in Fig. S4(b) in the Supplemental Material. We observe that the central field resolution of the ultra-wide FOV metalens is close to the diffraction limit at a single wavelength in the visible band.

To further characterize the wide FOV imaging capability, we select the number “7” of the USAF 1951 resolution test chart for imaging. By changing the filters and turning the rotary stage, the images with projection angles from 0 deg to 70 deg can be captured at different wavelengths. When the angle of the rotary stage is 65 deg, the projected image of the number 7 reflects the angle range of about 63 deg to 70 deg. Figure 2(f) shows the projected images of the number 7 with projection angles of 0 deg, 10 deg, 20 deg, 30 deg, 40 deg, 50 deg, and 65 deg at the wavelength of 532 nm. The contours of the number 7 can be easily identified in the projected images at all angles, confirming the wide FOV imaging performance of the metalens. Additional experimental images of the number 7 at other wavelengths are shown in Fig. S4(c) in the Supplemental Material. Note that the distorted image with a projection angle greater than 40 deg is the inherent distortion of all wide FOV imaging systems, and it can be corrected by mature algorithms. As a result, the wide FOV imaging ability of the ultra-wide FOV metalens is confirmed by clearly demonstrating the projection imaging in the range of 0 deg to 70 deg half-FOV.

Due to its self-attention mechanism design, the transformer module can capture longer distance context relationships, which can be interpreted as a global relationship modeling for image processing tasks.46 In the design of the ultra-wide FOV metalens at single-wavelength, PSFs of other wavelengths often suffer from severe mass loss, manifesting in the form of unconcentrated energy distribution, unfocused diffuse spots (Fig. S5 in the Supplemental Material), etc. These problems make the modeling of ultra-wide FOV metalens imaging more difficult for neural networks, and previous work has used traditional neural network architectures;47 however, the existing methods are still struggling to deal with such complex degradations. Fortunately, the transformer-based networks can handle the complex degradation described above for the ability of modeling long-distance dependencies.

In addition to the network structure, we point out that the training paradigm is also crucial. Considering the incompleteness of the theoretical simulation of the imaging process and the difference between theory and actual fabrication, the distortion and central bright speckle of the ultra-wide FOV metalens in the visible spectrum imaging hinder learning an effective model based on the pure theoretical approximation. Recent research has shown that deep-learning models trained at a large scale on similar tasks can learn transferable domain knowledge, so that it can be adapted to downstream tasks by a transfer learning manner.48 Therefore, we propose a two-stage paradigm to train a transformer network to recover the chromatic aberrations, distortion, and central bright speckle in the metalens imaging.

Figure 3 shows the proposed KD paradigm, including two stages: prior knowledge and data-driven. In the first stage shown in Fig. 3(a), we leverage the prior knowledge of metalens design to initialize the model with design parameters of the metalens in an unsupervised manner. Then, we perform data-driven learning to refine our neural network based on the collected real data in the second stage shown in Fig. 3(b) to drive its performance close to a conventional commercial lens. We use the same attention-based U-structured neural network49 (right part of Fig. 3) in both stages, so we can extract multiscale features and ensure that the recovered images of metalens are semantically consistent at various scales, producing a high-quality image, as expected. Note that we use the same loss function based on mean squared error in both stages as well.

Specifically, we first use the theoretical design parameters of the metalens and the theory of angular spectral propagation to simulate the PSF sets of the metalens in different FOVs and wavelengths.33 Since the design of the metalens is circularly symmetric, it is convenient to rotate these PSFs to obtain approximate PSFs of full fields collection, Image(λ)meta=∑θ∑ϕmask(θ,ϕ,λ)⋅[psf(θ,ϕ,λ)⊗Image(λ)H],(1)where Image(λ)meta means simulated image channel corresponding to wavelength λ, mask(θ,ϕ,λ) and psf(θ,ϕ,λ) are the mask and PSF in theory corresponding to FOV θ, rotation angle ϕ, and wavelength λ, respectively, and Image(λ)H represents an image corresponding to wavelength λ to be convolved. It is worth noting that, compared to previous works that convolve images with PSF of a single incident angle at each wavelength,34 we incorporate the PSF of all incident angles into the simulation, so that we are able to take into consideration the strong variations of the PSF at nondesignated wavelengths during our modeling. The detailed processing about PSF generation can be found in Section S3 in the Supplemental Material. Note that the data set we collected includes the aberration information of each FOV, so that our initialized neural network can capture the prior knowledge about the aberration distribution of the imaging, allowing the network to achieve faster convergence and better performance in the second stage.

We use the data-driven approach instead of the measured PSF set-driven method33^,34 in the second stage to circumvent the following problems. Existing single-wavelength wide FOV metalenses with a small front aperture have a central bright speckle problem at nondesigned wavelengths, which becomes serious with the increase of the incident angle. Unfortunately, so far there are no accurate theoretical models to estimate the central bright speckle. Moreover, the intensity variation and spatial inhomogeneity of PSFs at different angles of incidence and at nondesigned wavelengths make it difficult for the measured PSF set to restore the real image effect. With such large differences in PSF intensities, the measured PSF set ensemble will have a greater loss of precision, resulting in a more tedious and arduous task to measure the PSF set than our data-driven method.

In the second stage [Fig. 3(b)], we build an image acquisition processing system to efficiently acquire real data for fine-tuning our model. The image acquisition processing system shots the images displayed on the LCD screen (Portkeys LH5P II, 5.5″, 1920×1080) as the scenes by a conventional commercial lens (Sigma Art Zoom lens) or metalens, and finally collects the image pair captured by the CMOS sensor (e.g., IMAX 335) and commercial Sony sensor (e.g., A7M3, Sony), respectively. More details about this image acquisition processing system can be found in Section S4 in the Supplemental Material. Section S5 in the Supplemental Material further describes our data processing procedures; that is, once the process is established, it may be possible to cascade data-processing flows and neural networks to quickly process imaging. The ablation experiments shown in Section S7 in the Supplemental Material demonstrate the effectiveness of our method.

In addition, we enhance the model by using the equivariant in imaging process throughout the experiment by the following equation: T(I)=T(psf⋅I),(2)where T is a particular transformation, I is the imaged object, and psf is the PSF corresponding to the one-to-one imaging process. By utilizing the equivariant of physical processes to augment data, the model can discover potential physical properties for better robustness on unseen data.50

To demonstrate the performance of the ultra-wide FOV metalens combined with the neural network, we conduct an experimental comparison by imaging different types of images in the image acquisition processing system. Considering the trade-off between data collection cost and recovery effectiveness, we collected 1000 images to validate our approach, 800 as training data and 200 as test data. As shown in Fig. 4(a), the image data of scenes (e.g., projected by the LCD screen) are imaged by the naked ultra-wide metalens, and then captured by the microscopic system consisting of a 10× objective (MPLFLN10×BD, Olympus), an adapter tube lens (1-62922, Navitar), and a CMOS sensor (A7M3, Sony). Original images captured by the metalens and corresponding recovery results from our neural networks, UNet & KD paradigm (UNet trained with KD paradigm), and other traditional image enhancement algorithms are shown in Fig. 4(b). Compared with the unrecovered image of the naked ultra-wide FOV metalens on the leftmost of Fig. 4(b), the contrast and sharpness of the images restored by the sharpened Laplacian algorithm and the multiscale retinex with color restoration (MSRCR) algorithm are not improved much, due to uncorrected background noises. The images recovered by the UNet & KD paradigm can effectively eliminate the central bright speckle, but the contrast and sharpness of the images are not good enough. In contrast, high-contrast and panchromatic aberration correction images can be recovered by our method (transform-based neural network trained with KD paradigm). From the zoom-in images in Fig. 4(b), it is clear that the contrast of the object’s contour boundaries has been well refined, and the contour boundaries no longer have color overlay vignetting due to magnification chromatic aberration. More information on the comparison of other traditional convolutional networks with our image recovery neural network (transform-based network) is provided in Section S8 in the Supplemental Material. Therefore, our image recovery neural network offers a considerable enhancement in color similarity, contrast, and edge sharpness compared to traditional algorithms and other traditional convolutional networks.

To demonstrate a proof-of-concept application, we package the metalens with a CMOS image sensor into a miniature and portable meta-camera with a volume of 9.07mm×9.07mm×1.57mm. Figure 5(a) shows the photograph of the meta-camera system, including the diaphragm, sleeve, base, CMOS image sensor (IMX335, Sony), and core optical element of the wide FOV metalens. The advancement of our proposed compact integration approach is that we have built a precision assembly platform to ensure the integrated camera modules are versatile and practical. The professional design of the support structure greatly reduces the complexity and difficulties caused by inclination and eccentricity in assembly. The most critical step in the assembly process is to ensure that the distance between the metalens sample and the CMOS sensor is accurate enough. For this purpose, the thread structure is designed and manufactured between the sleeve and the base to facilitate precise adjustment of the image clarity of the camera module. In addition, to ensure an accurate bond between the components, we use ultraviolet curing adhesive for sealing with a curing time of 2 min.

To exhibit the capability of the neural meta-camera, we placed an LCD screen at different working distances from the meta-camera so that it could capture images with a large FOV [Fig. 5(b)]. Following the setting in the metalens demonstration, we use 800 images for training and 200 images for evaluation. Figure 5(c) shows the results at a working distance of 2 cm before and after recovery of the neural meta-camera and the neural ultra-wide FOV metalens. Compared to the ultra-wide FOV metalens, the original images captured by the meta-camera have a more severe central bright speckle and color cast. The exacerbation of the central bright speckle is due to the burr and irregular shape of the aperture of the diaphragm caused by a processing error, while the color cast is derived from the difference in spectral response curve of CMOS image sensors between commercial Sony sensor (A7M3) and IMX335. Cartoon images from an alarm clock and a blue bed show that chromatic aberrations and central bright speckle are greatly improved after recovery through our method. The attention mechanism leads to a wider receptive field, combined with a multiscale structure, allowing for a more complete removal of global information-related bright speckle in a central position. Despite the images captured by the meta-camera having a stronger bright speckle than those captured by the ultra-wide FOV metalens only, the proposed neural network can still eliminate them. To quantitatively evaluate the performance of the neural meta-camera, we test a black-and-white target image. The captured images of the black-and-white target are shown in Fig. 5(d); the image from the neural meta-camera has no central bright speckle and color casts, and the line contours are clearer than those using only the meta-camera. Figures 5(e) and 5(f) show the intensity distribution at the center and edge of the captured image, where the solid and dashed lines correspond to images captured only from the meta-camera and improved by the neural network, respectively. The calculated contrasts at the center and edge parts of the target images are increased by 13.5 times and 2.7 times, i.e., 0.834, 0.846 for the neural meta-camera, and 0.062, 0.313 for the meta-camera only, respectively. The high contrast values indicate high edge sharpness in neural meta-camera imaging. In conclusion, our neural meta-camera enables high-quality, wide FOV, and full-color imaging.

To assess the practicability and feasibility of the neural meta-camera in an actual scene, we captured and recovered the images in two scenarios. One is the imaging of three monitor screens at different working distances; the other is the imaging of multiple objects of various colors arranged at different depths in an actual scene. In the first scenario, we obtained recovery images at the working distances of 1.3, 12, and 44.5 cm, as shown in Fig. S17 in the Supplemental Material. It can be seen that the image restoration clarity and color comparison are uniform at different working distances. The calculated peak signal-to-noise ratio and structure similarity index measure (SSIM) values (as shown in Table S4 in the Supplemental Material) further emphasize quantitatively the quality of image restoration at different distances.

In the other scenario, we further capture and recover the image of letters and dolls at different working distances in an indoor scene. We set up a dual optical path data acquisition system [Fig. S18(a) in the Supplemental Material] based on a cube beam splitter to obtain pixel-level aligned data sets. As shown in Fig. S18(b) in the Supplemental Material, in the recovered image from the neural meta-camera, the letters are clearer, and the dolls at different working distances of 40, 55, and 85 cm can also be identified. Although the recovered image lacks detail, its central bright speckle and chromatic aberration are greatly improved compared to the original image from the meta-camera. In addition, based on the imaging data from the actual scene, we compare the performance between the imaging of the meta-camera and the traditional camera on the multi-label image classification task. The data from the meta-camera achieve a precision of 96.47%, while the data from traditional camera achieve 96.73%. Experiments demonstrated that the imaging of the meta-camera did not show significant performance differences in recognition tasks compared to imaging from a traditional camera, which hints at the potential of meta-camera for classification and recognition application.

Our work demonstrates a neural meta-camera for ultra-wide FOV and full-color imaging in single shot without scanning or image stitching. The neural meta-camera consists of an ultra-wide FOV metalens, a CMOS image sensor, and the image recovery neural network. Due to the high-precision assembly technology, our neural meta-camera is only 9.07mm×9.07mm×1.57mm in volume, including the support structure and the CMOS image sensor. The neural meta-camera overcomes chromatic aberration, distortion, central bright speckle, and background noise through image recovery neural network and successfully achieves full-color imaging with high contrast over a wide FOV. Such a neural meta-camera is an exemplary case in imaging systems with miniaturization, functionality, wide FOV, and high-quality performance at the same time.

The proposed KD paradigm is theoretically uncoupled from the design approach, so it is extended to applications such as depth of field synthesis and outdoor imaging. Under ideal conditions, the model can recover images at the speed of 48 frames per second on the RTX 3090 GPU, which opens up the possibility of real-time51 processing in the future. This novel neural meta-camera module paves the route for meta-optics for the thinner, lightweight, and more compact visible full-color imaging system, such as noninvasive52 endoscopy, robot navigation, micro-intelligent systems, and engineering surveying.
